Palfinger P 370KS Diagrams

Working diagrams
Working diagrams
Palfinger P 370KS
on
MAN 18.XXX 16t
The working diagrams shown below have the following preconditions:
Solid line:
Standard working diagram
Working height = height of basket bottom + 2.0 m
The basket is in basic position (not turned) and retracted
The following applies generally:
All specifications refer to standard aluminum basket without additional equipment
Maximum inclination 0,5°
Set-up inclination is max. 2° with automatic range adjustment.
Note on working diagram:
Additional attachments that deviate from the standard reduce range and basket load
Special baskets have different ranges
Reach at plastic workman basket ~ 0,8m reduced
Permitted maximum basket load according to technical description
The outreaches are approximate dimensions and depend on the chassis, the type of support
and the lifting platform's additional equipment.
Illustrations of truck and unit are only of symbolic nature and do not allow any conclusions
regarding technical design.
Subject to technical change!
B5035_002_A_V1.docx Page 1 of 10
