- Page 1 Dynatel 2210 Cable Locator Operators Manual October 1996 78–8097–5171–8 Revision A...
- Page 2 Dynatel 2210 Cable Locator Operators Manual The information in this manual is proprietary to 3M and may not be reprinted or otherwise copied without the express written permission of 3M. 1996 3M...
- Page 3 Lab – Technical Communications 6801 River Place Boulevard Austin, Texas 78726–9000 For Technical Service call: 800/426 8688 (outside the U.S.A. call 512/984 2575) Dynatel is a Trademark of 3M Dyna-Coupler is a Trademark of 3M Duracell is a registered trademark of Duracell Inc.
- Page 4 Refer to Receiver Operation to prepare the receiver and locate the cable. For passive power locating, go directly to Receiver Operation. Note: For more detailed locating instructions and advanced locating techniques, ask your 3M sales representative for a publication called Cable and Pipe Locating Techniques.
- Page 5 Induction Method Transmitter Hinge Near End Suspected Far End Ground Cable Path Ground 1. Place the transmitter on the ground over the target cable with the lid hinge in line with the cable path. Dyna-Coupler Method Note: The coupler jaws (Optional Accessories Required) Pedestal must fully close for tone...
- Page 6 Receiver Operation: 2210 577 Hz 33 KHz Receiver Front Panel Gain Adjust 1. Press to turn receiver on and see battery level. Hold down for continuous Battery Test. If bar graph is to the left of the battery level mark, replace batteries. Note: when batteries are low, the battery test indicator remains on.
- Page 7 Technical Information: Active Frequencies: 574.9 Hz and 32768 Hz (Actual) Passive Frequency: 50/60 Hz Power Battery Life: Receiver: 84 hours, typical (Normal audio level) Transmitter: 50 hours, typical (Normal output) 10 hours, typical (High output) Recommended Batteries: Duracell MN1500 AA Alkaline Duracell MN1400 C Alkaline Temperature Range: Operating: -4 F to 122 F (-20 to 50 C) Storage:...
- Page 8 IMPORTANT NOTICE: Before utilizing the product the user should determine the suitability of the product for its intended use. The user assumes all risks and liability whatsoever in connection with such use. 3M’s WRITTEN WARRANTY FOR THE PRODUCT IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
