Floor Hugger
Low-Profile Electronic
Platform Scale
Owner's Manual
CARDINAL SCALE MFG. CO.
1905-M142-O1 Rev D
203 E. Daugherty, Webb City, MO 64870 USA
Ph: 417-673-4631 • Fax: 417-673-2153
05/01
Printed in USA
www.cardinalscale.com
Technical Support: Ph: 866-254-8261 • tech@cardet.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Floor Hugger and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cardinal Floor Hugger

  • Page 1 Floor Hugger Low-Profile Electronic Platform Scale Owner’s Manual CARDINAL SCALE MFG. CO. 1905-M142-O1 Rev D 203 E. Daugherty, Webb City, MO 64870 USA Ph: 417-673-4631 • Fax: 417-673-2153 05/01 Printed in USA www.cardinalscale.com Technical Support: Ph: 866-254-8261 • tech@cardet.com...
  • Page 3: Table Of Contents

    INTRODUCTION TABLE OF CONTENTS Your low profile platform scale is designed and Introduction ............1 manufactured with quality and reliability. Installation ............2 Optional inclined ramps may be installed for easy approach and exit of scale. Four electronic Calibration Procedure ........3 load cells support the scale platform and are Trim Adjustment ..........
  • Page 4: Installation

    INSTALLATION The following section outlines procedures for unpacking and installation of your scale. Read this entire section carefully before attempting to unpack or install this scale. FIGURE No. 1 Inspect the shipping container for any signs of damage such as exterior dents and scratches. It is the responsibility of the purchaser to file all claims with the shipping company for damages or loss incurred during transit, unless this responsibility has been accepted by the Seller in its proposal.
  • Page 5: Calibration Procedure

    INSTALLATION Continued The lower frame assembly (as seen in Figure No. 2) contains shipping bolts used to keep the platform secure during transit. These shipping bolts must be removed, (either 2 or 4 depending on the model purchased) and conveniently stored for re-installation before moving scale. We recommend the scale be fastened to the floor using the holes found in the scale anchoring plates.
  • Page 6: Trim Adjustment

    CALIBRATION PROCEDURE Continued Place test weight equal to ten percent of the scales capacity over each of the four load cells, one at a time. Record each displayed weight. If difference in displayed weight exceeds ±.05 percent of the test weight, trimming adjustments for your load cells must be performed. Refer to TRIM ADJUSTMENT Section for further instruction.
  • Page 7: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE If difficulty is encountered with the operation of the scale a visual check of the scale platform should be made to make certain operation is not restricted by foreign material, such as packing material, etc. The following trouble shooting guide should prove useful in isolating and correcting a problem with the scale.
  • Page 8: Interconnection Diagram

    INTERCONNECTION DIAGRAM Figure No. 4...
