sematic SDS DC-PVM Rel. 3.0 Manual page 36

9.11. Protective Device Logic Kn setting by means of the Handset
• See § 6.12 for the meaning of this parameter
• Using keys and
Device Logic Option
• Press the "OK" key to confirm the choice
• The following options are viewed on the display:
• ON OBSTRUCT. : CLOSED
• ON OBSTRUCT. : OPEN
• Using keys and
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
• "BACK": Press key F1 to restore the menu PROFILE SETTING
• "MENU": Press key F3 to restore the MAIN MENU
9.12 Closing Rotation
• See § 6.13 for the meaning of this parameter
• Using keys
CLOSING ROTATION Option
• Press the "OK" key to confirm the choice
• The following options are viewed on the display:
• CLOCKWISE
• ANTICLOCKWISE
• Using keys and
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
• "BACK": Press key F1 to restore the menu PROFILE SETTING
• "MENU": Press key F3 to restore the MAIN MENU
© SEMATIC All rights reserved
Changes can be made without notice
see www.sematic.com for latest release
, run through the GENERAL OPTIONS and choose the Protective
, choose the required option and press the "OK" key to confirm it
and , run through the GENERAL OPTIONS and choose the
, choose the required option and press the "OK" key to confirm it
