2.1 Speed profiles
V (m/s)
MAX.
1.1 m/s
O1
Ka
Kc
La
Lc
OPENING CYCLE
01 Opening acceleration
02 Opening high speed
03 Opening deceleration
CLOSING CYCLE
C1 Closing acceleration
C2 Closing high speed
C3 Closing deceleration
w w w . s e m a t i c . c o m
O2
O3
10
C2
C3
C1
KEY
Ka Door opening
Kc Door closing
La Open limit
Lc Close limit
Closing cycle
Active reversing system
Opening cycle
