Application Guidelines

MLM/MLZ116

Brazed connection-MLZ/MLM116 T4BC5
Discharge
1"1/8
Suction
1"5/8
188
652
617
301.5
214
(29.5)/Without compression
(28.0)/With compression
195
171
90°
428
30°
10
FRCC.PC.035.A5.02

Dimensions

Ø 266
Ø 257.4
531±1.2
Oil sight glass
92.5
76.6
Ø 318
345
4x Ø 19.43
279.4
60°
181
304.8 371
90°
212
Terminal box
Black Blue Brown
Faston 1/4" tabs
Power supply
Refer to section "Ordering information and packaging" for overview of shipped mounting accessories
Rotolock connection-MLZ/MLM116 T4QC5
Discharge
1"1/8
Suction
1"5/8
188
652
617
301.5
214
(29.5)/Without compression
(28.0)/With compression
183
157
428
30°
Grommet
M1-M2
control circuit
Steel mounting sleeve
Module
power supply
Rubber grommet
Sump heater
Single compressors
Ø 266
Ø 257.4
76.6
Ø 318
345
4x Ø 19.43
279.4
60°
181
304.8
90°
212
All dimensions in mm
HM 8 bolt
Lock washer
Compressor
base plate
Flat washer
Nut
531±1.2
371
28 mm
