- Page 1 Magnum P62F-Series Corporate Headquarters Ethernet Switches GarrettCom, Inc. 213 Hammond Avenue Fremont, CA 94539 Phone: 510.438.9071 Fax: 510-438-9072 Web: www.GarrettCom.com Email: support@Garrettcom.com www GarrettCom com www GarrettCom com www GarrettCom com...
- Page 3 NEBS is a trademark of Telcordia Technologies UL is a registered trademark of Underwriters Laboratories GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a registered trademark of GarrettCom, Inc. Important: The Magnum P62F-Series Ethernet Switches contains no user serviceable parts.
- Page 4 Magnum P62F-Series Ethernet Switches Installation and User Guide (11/01) Contacting GarrettCom, Inc Please use the mailing address, phone and fax numbers and email address listed below: GarrettCom, Inc. 213 Hammond Ave. Fremont, CA 94539 Phone (510) 438-9071 Fax (510) 438-9072 Website: http://www.GarrettCom.com...
- Page 5 MAGNUM ETHERNET CONNECTIVITY PRODUCTS "DESIGNED AND MANUFACTURED IN THE USA" Overview GarrettCom, Inc. offers the Magnum line of Ethernet LAN physical layer connectivity products with industry-standard functionality. Magnum products are available worldwide through OEMs, integrators, representatives, and international distributors. 4K-Series Switches, 100 & 10Mbps, copper ports with optional fiber port, with auto-negotiating full switching performance Quad-Series Fiber Switches, 100 &...
-
Page 7: Table Of Contents
REV A 04/01: This revision is the initial release of the P62F Ethernet Switches user manual. Rev B 08/01: This revision includes the update of Section 2.2.1 and addition of Power Source Extended. Temp, Section 3.3.2/ 3.3.3 for Magnum P62F-5V Rev C 11/01: This revision includes the Magnum P62F-NOF, and metal mounting. www GarrettCom com... -
Page 8: Specifications
Power Consumption: 10 watts typical. DC-DC Converter Rating: 5VDC, 2Amps Power Supply (External 125VDC Power Supply (PSX-T) for P62F-5V Power Input Voltage: 100 to 275 VDC (nominal rating of 125VDC) Power Consumption: 15 watts typical. DC-DC Converter Rating: 5VDC, 3Amps www GarrettCom com... - Page 9 F/H (RJ-45 ports only): ON = full-duplex, OFF = half-duplex MTBF (Bellcore method) sales@GarrettCom.com Over 15 years MTBF. Email for details Agency Approvals UL Listed (UL 1950), cUL, CE Emissions: meets FCC Part 15, Class A Warranty: Three years, return to factory Made in USA www GarrettCom com...
-
Page 10: Ordering Information
70VDC auto-ranging. Steel case acts as a heat sink. Plenum- and outdoor-temperature rated. Magnum P62F-1M1SSC: Same as P62F-2MSC, but with one multi-mode SC- type and one 20Km single mode SC fiber connectors. Magnum P62F-2SSC: Same as P62F but with two 20Km single-mode SC-type fiber connectors. www GarrettCom com... - Page 11 “+”, “-“, and GND Magnum P62F models with other fiber connector types and combinations available, request quote for additional information. GarrettCom, Inc. reserves the right to change specifications, performance characteristics and / or model offerings without notice. www GarrettCom com...
-
Page 12: Introduction
To validate the product warranty, please complete and return the enclosed Product Registration Card to GarrettCom, Inc. as soon as possible. In the event there are items missing or damaged, contact your supplier. If you need to return the unit, use the original shipping container. -
Page 13: Product Description
Each P62F Ethernet Switch is non-blocking on all ports and has 1MB packet buffers and a 16K-node address table for advanced performance. A Magnum P62F Ethernet Switch, armed with store-and-forward switching ability, filters all faulty packets to minimize traffic congestion. www GarrettCom com... -
Page 14: Magnum P62F-Series Chassis
The AC Power Source, PSX-A, is equipped with worldwide range of 85-264vac, 47- 63Hz , auto-ranging with 5VDC , 3Amps Power output. For both models , the military style www GarrettCom com... -
Page 15: 100Mbps Fiber Ports, Sc Connectors
Since there is no way to filter frames with a bad CRC (the entire frame must be present in order for CRC to be calculated), the www GarrettCom com... - Page 16 For 10 Mb-to-10 Mb or 10 Mb-to-100Mb or 100Mb-to-10 Mb forwarding, the latency is 15 microseconds plus the packet time at 10Mb. For 100Mb-to-100Mb forwarding, the latency is 5 microseconds plus the packet time at 100Mb. www GarrettCom com...
-
Page 17: Features And Benefits
Wide-range 24VDC and -48VDC power input The P62F Ethernet switch is designed for 20-70 VDC auto-ranging power input. DC power is highly reliable and convenient in out-of-the-way locations. MTBF over 15 years, per Bellcore calculation method sales@garrettcom.com Email for MTBF details. www GarrettCom com... -
Page 18: Applications
Magnum P62F Magnum P62F Magnum P62F Magnum P62F Magnum P62F Magnum P62F Figure 2.6.1: A P62F connects combinations of 10 Mbps and100Mbps network devices and provides a Fast Ethernet fiber backbone for access to the central control station www GarrettCom com... - Page 19 Ethernet network facility as part of the building infrastructure. The steel enclosure and 20-70VDC power input qualifies the Magnum P62F to provide a dependable solution for any temperature un-controlled location environments. The rugged enclosure with cable strain feature gives extra protection and security to the LAN users. www GarrettCom com...
-
Page 20: Installation
(cable connectors at the bottom) position. The base plate of the unit has screw holes cut out, two top and two bottom. The spacing for the mounting screws is a rectangle 3.35” x 8.25” (8.25cm x 21cm) center-to-center. Four user-supplied screws attach the P62F base plate to the vertical mounting surface. www GarrettCom com... -
Page 21: 3.2 Connecting Ethernet Media, And Special Strain-Relief Feature
Using standard twisted pair media, insert either end of the cable with a RJ-45 plug into the RJ-45 connector of the port. Note that, even though the connector is shielded, either unshielded or shielded cables and wiring may be used. www GarrettCom com... -
Page 22: Connecting Fiber Optic Sc-Type, "Twist-Lock
When using single-mode fiber cable, be sure to use single-mode fiber port connectors. Single-mode fiber cable has a smaller diameter than multi-mode fiber cable (9/125 microns for single-mode, 50/125 or 62.5/125 microns for multi-mode where xx/xx are the diameters of the www GarrettCom com... -
Page 23: Power Budget Calculation For P62F Fiber Media
The 100Mb fiber segment must operate in full-duplex (FDX) mode, and • The worst-case OPB of the fiber link must be greater than the fiber cable’s passive Attenuation. (Attenuation = Cable loss + LED aging loss + Insertion loss + safety factor) www GarrettCom com... -
Page 24: Connecting To Nics Which Support Auto-Negotiation
+ve potential lead or -ve potential lead. The more +ve potential lead will connect to the post labeled “+ve” and the rest to the “-ve”. The GND can be hooked up at the last. When power is applied, the green PWR LED will illuminate. www GarrettCom com... -
Page 25: Powering The Magnum P62F-5V With External (Psx- A) Ac
The 125VDC power source (PSX-T) provides a rugged power supply enclosed in a metal case that also acts as a heat sink, enabling extended temperatures to be accommodated. The PSX-T also includes reverse- www GarrettCom com... - Page 26 (such as pedestal) that has good heat conducting properties. Remove rubber “feet”, if present, to enhance metal-to-metal contact and provide the best heat transfer away from the PSX unit. www GarrettCom com...
-
Page 27: Cable Strain-Relief Feature
This feature provides a more reliable and robust installation and operation. The figure below illustrates the strain-relief feature, using tie-wraps. www GarrettCom com... -
Page 28: Operation
They are self-learning, so that as nodes are added or removed or moved from one segment to another, the P62F automatically keeps up with node locations. An address-aging algorithm causes least-used addresses to fall out in favor of new www GarrettCom com... -
Page 29: Auto-Negotiation And Speed-Sensing
ON = Full-Duplex and Link, OFF = Half-Duplex and / or no Link. LK/ACT: Per port, steady ON for LINK with no traffic, blinking indicates port is transmitting and receiving. 10/100: Per port, ON = 100Mbps; OFF = 10 Mbps (when LINK is made). www GarrettCom com... -
Page 30: Troubleshooting
However, if you are unsure of the procedures described in this section or if the Magnum P62F Ethernet Switch is not performing as expected, do not attempt to repair the unit; instead contact your supplier for assistance or contact GarrettCom Customer Support. -
Page 31: When Calling For Assistance
Return Material Authorization (RMA) Procedure All returns for repair must be accompanied by a Return Material Authorization (RMA) number. To obtain an RMA number, call GarrettCom Customer Service at (510) 438- 9071 during business hours in California or email to support@garrettcom.com. When calling, please have the following information readily available: Name and phone number of your contact person. -
Page 32: Shipping And Packaging Information
GarrettCom, Inc. warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of shipment by GarrettCom. During this warranty period, GarrettCom will repair or, at its option, replace components in the products that prove to be defective at no charge other than shipping and handling, provided that the product is returned pre-paid to GarrettCom.
