  • Page 1 Yaasa Desk Pro II Extended original operating instructions...
  • Page 2 The Yaasa Desk Pro II is an electronically-adjustable sit-stand table (table) for home and office use. The Yaasa Desk Pro II with electronic height adjustment was tested to fulfil the requirements of safety, durability and stability according to EN 527-2:2016 + A1:2019.
  • Page 3 2 minutes. After, the table must “rest” for 18 minutes before it can be operated again. The Yaasa Desk Pro II features a collision detection system (Intelligent System Protection, ISP). The ISP Function aims to reduce system damage and injuries through crushing.
  • Page 4 While the table is being used, no one may stand or sit on the table, nor may they climb or lie underneath it. During reset processes there is a risk of crushing between the table legs and feet. When the table moves upwards or downwards, you must maintain a safe distance in order to avoid collisions or crushing between the table and its surrounding objects or persons.
  • Page 5 TECHNICAL PROPERTIES & PRODUCT DETAILS Size Weight 139 cm x 75 cm 36,64 kg 54,5- 122,5 160 cm x 80 cm 39,50 kg 54,5- 122,5 180 cm x 80 cm 41,41 kg 10,8 54,5- 122,5...
  • Page 6 Frame: Powder-coated steel with aluminum feet and 4 levelers with a 10 mm thread. Adjustment interval: 62 to 128 cm Adjustment speed: 38 mm/s Column Type 3 Stage Max. Load: 80 kg Sound level: Lw,A,max = 63dB(A) Weight (Complete Product) 37 - 41.5 kg Table frame and packaging: 26 kg...

  • Page 7: Scope Of Delivery

    SCOPE OF DELIVERY F G J Package 1 of 2 A 1 x Table frame with legs B 2 x Table feet with levelers C 2 x Siderail D 4 x Plastic covers for siderails E 1 x Operational control (cable attached) with memory function (handset) F 1 x Mains Adapter G 1 x Power Cable H 1 x Cover for mains adapter...
  • Page 8 ASSEMBLY INSTRUCTIONS The table must only be assembled according to the assembly instructions. The Assembly instructions are contained on a separate sheet (package 1 of 2).
  • Page 13 The following cable routing is recommended: Power Motor 1 Motor 2 SETUP AND USE OF THE TABLE After assembly, the levelers on the feet must be adjusted so that the table stands evenly and is stable. Position the table in the vicinity of an outlet and plug in the power cable. The table is now ready for use.

  • Page 14: Faqs And Troubleshooting

    FAQs AND TROUBLESHOOTING Complete troubleshooting instructions and FAQs are available on www.yaasa.eu. FUNCTIONS Changing the table height Press the arrow buttons on the handset in order to move the table upwards or downwards. The desktop moves up or down until you release the key, or until the maximum or minimum desk height is reached.
  • Page 15 Move the table to the desired height (e.g. 73 cm). Press the Save button. S - is shown on the display. Press the desired memory position button, e.g. 2. S 2 is shown on the display. The desired height is now saved to the corresponding memory position button. To move the table to the saved position, press and hold the memory button until the table reaches the desired height and stops.
  • Page 16 Factory Reset To restore the Yaasa Desk Pro II to its factory settings: Hold the following buttons for 3 seconds: (Memory position buttons 1 and 2 and the “Table up” button) The display shows S and a number Press the “table down”...

  • Page 17: Cleaning And Care

    CLEANING AND CARE Before cleaning or servicing, the table must be disconnected completely from the power outlet. Normal and moderate soiling of the tabletop can be cleaned with a dry paper towel, a clean cloth (dry or slightly damp) or with a non-abrasive sponge. Use regular household cleaning agents for this purpose.
  • Page 18 For any problems or questions regarding the product, please contact the online shop from which you bought the product by phone or email. For all other information, recurring problems, or for further questions, please contact: Yaasa Living AG St. Leonhardstrasse 45 9001 St. Gallen, Switzerland www.yaasa.eu info@yaasa.com © Yaasa Living AG 2021...

  • Page 19: Ec/Eu Declaration Of Conformity

    9001 St. Gallen, Switzerland Person authorized to compile Stephan Egger the technical documents: Yaasa Living AG, President of the Board of Directors St. Leonhardstrasse 45 9001 St. Gallen, Switzerland The manufacturer hereby declares, on its sole responsibility, that the following product:...
  • Page 20 Yaasa Living AG St. Leonhardstrasse 45 CH-9000 St.Gallen www.yaasa.de www.yaasa.eu 01/2021...
