- Page 1 Application Guidelines Copeland ZX Small ™ Outdoor Refrigeration Units...
-
Page 2: Table Of Contents
About these guidelines ....................1 Safety instructions .................... 1 1.1 Icon explanation ......................... 1 1.2 Safety statements ......................1 1.3 General instructions ......................2 Product description ..................3 2.1 General information about Copeland ZX Small refrigeration units ........3 2.2 EU Ecodesign Directive 2009/125/EC ................3 2.3 Main product features ...................... - Page 3 3.3.2 Maximum operating currents for cable selection ..........13 3.3.3 Electrical protection standard (protection class) ..........13 3.3.4 Main fuses ......................14 3.4 Location & fixings ......................14 Start-up & operation ..................15 4.1 Evacuation ........................15 4.2 Charging procedure ......................15 4.2.1 Refrigerant charging procedure ................
-
Page 4: About These Guidelines
Manufacturer’s Declaration, available relevant standards please refer www.climate.emerson.com/en-gb. These instructions should be retained throughout the lifetime of both the compressor and the refrigeration unit. You are strongly advised to follow these safety instructions. Icon explanation WARNING CAUTION This icon indicates instructions to avoid This icon indicates instructions to avoid personal injury and material damage. -
Page 5: General Instructions
General instructions WARNING System breakdown! Personal injuries! Never install a system in the field and leave it unattended when it has no charge, a holding charge, or with the service valves closed without electrically locking out the system. System breakdown! Personal injuries! Only approved refrigerants and refrigeration oils must be used. -
Page 6: Product Description
Product description General information about Copeland ZX Small refrigeration units Emerson has developed the Copeland ZX Small outdoor refrigeration unit to meet primarily the needs of the food retail and food service sectors. It is a refrigeration air-cooled condensing unit that uses the latest Copeland patented scroll technology. -
Page 7: Product Nameplate
Outer dimensions Liquid Sound level Weight Unit length / width / height receiver size (dB(A)) (kg) with closed cover (mm) (litres) @ 50 Hz ZXME-013E ZXME-015E ZXME-018E 900 / 350 / 605 ZXLE-018E ZXLE-023E ZXLE-028E Table 2: ZX Small refrigeration unit features The drawings hereafter show the overall physical dimensions of the Copeland ZX Small refrigeration units in millimetres: Figure 1: Dimensions of ZX Small refrigeration units (all models) -
Page 8: Nomenclature
Application limits For application envelopes, please refer to the compressor application envelopes which can be found in Copeland Select software, available at www.climate.emerson.com/en-gb. Copeland ZX Small refrigeration units can be used at ambient temperatures from -15 to +43 °C. For lower ambient temperatures please contact your local Application Engineering representative. -
Page 9: P&I Diagrams
P&I Diagrams 2.8.1 P&I diagram for ZXME units Figure 3: P&I diagram for ZXME units Position Description Scroll compressor Condenser Liquid receiver Filter drier Sight glass Service valve liquid line Service valve suction line Crankcase heater Discharge line thermostat High-pressure limiter Low-pressure limiter Fan speed controller Table 5: Legend of the P&I diagram for ZXME units... -
Page 10: P&I Diagram For Zxle Units
2.8.2 P&I diagram for ZXLE units IMPORTANT Absence of insulation on the liquid line in ZXLE units! Air moisture condensation and lack of performance! Moisture will condensate on the liquid line and cause water droplets. The liquid line can pick up additional heat from the ambient which will adversely affect the subcooling desirable for the liquid refrigerant before it enters the expansion valve. -
Page 11: Main Components Description
4. Electrical connections 5. Service valves Figure 5: ZX Small unit housing NOTE: For detailed information about unit components and spare parts, please refer to the compressor application guidelines and to the Copeland Spare Parts Catalogue available at www.climate.emerson/en-gb/tools-resources. AGL_Unit_ZX_Small_E_Rev03... -
Page 12: Main Control & Safety Features
2.10 Main control & safety features Copeland ZX Small refrigeration units feature a whole range of control and safety components. 2.10.1 Suction pressure control The unit is switched on and off by means of a PS1 low-pressure switch. Caution: The unit does not have any cycling protection. The adjustment of the low-pressure switch must be done in such a way that the unit will not switch on and off more than 10 times per hour during normal operation. -
Page 13: Installation
Installation WARNING High pressure! Injury to skin and eyes possible! Be careful when opening connections on a pressurized item. Copeland ZX Small refrigeration units are delivered with a holding charge of dry air at 1.68 bar. The refrigeration unit should be located in such a place to prevent any dirt, dust, plastic bag, leaves or papers from covering the condenser and its fins. -
Page 14: Brazing Recommendations
IMPORTANT Connection sizes! Unsuitable refrigerant flow rate! Do not assume that the service connection sizes on the unit (at the service valves) are in fact the correct size to run your interconnecting refrigeration pipes. The service valve sizes have been selected for convenience of installation and in some cases (larger units) these may be considered too small. -
Page 15: Brazing Procedure
Figure 7: Brazing – Sectional view 3.2.3 Brazing procedure For the brazing of the tubes, please refer to Figure 8 and procedure hereunder: ▪ Fit the copper tube into the unit tube. ▪ Heat area 1. As the tube approaches brazing temperature, ▪... -
Page 16: Maximum Operating Currents For Cable Selection
All accessible metallic parts or objects within 3 metres of the refrigeration unit, eg, metal pipes, fence, ladders, railings etc... must be grounded with a dedicated grounding connection. A separate ground connection is provided on the baseplate of the unit. Figure 9: Additional ground connection on the unit baseplate After commissioning, make sure to reconnect the ground wire to the front cover. -
Page 17: Main Fuses
3.3.4 Main fuses WARNING Main switch "On"! Danger of electric shock! Before changing the fuses, turn the isolating switch off to de-energize the unit. Circuit Fuse size Fuse range Ident number Control circuit Fuse 5 x 20 3.15 A 3233538 Main power supply Fuse 10 x 38 12 A... -
Page 18: Start-Up & Operation
Start-up & operation Before commissioning, ensure that all valves on the refrigeration unit are fully opened. Evacuation CAUTION System pressure below atmospheric pressure! Compressor damage! Never energize the unit without minimum refrigerant charge in the system. There is a risk of malfunction of the unit in deep vacuum operation which can cause compressor damage. -
Page 19: Oil Charging Procedure
NOTE: The oil level should be approximately halfway up the sight glass. As mentioned in paragraph 2.6.1 "Qualified refrigerants and oils", Emerson recommends using one of the following oil types: ▪... -
Page 20: Checks Before Starting & During Operation
Checks before starting & during operation IMPORTANT Liquid valves not fully opened! Liquid trap! The valves on the liquid line should be fully open, in order to prevent liquid trapping. Before a system runs for the first time: ▪ Check that the valves on the liquid line are fully open. ▪... -
Page 21: Maintenance & Repair
NOTE: For more information about unit components and spare parts, please refer to the compressor application guidelines and to the Copeland Spare Parts Catalogue available at www.climate.emerson.com/en-gb/tools-resources. Safety devices During regular maintenance, all mechanical safety devices such as high- and low-pressure switches must be checked for proper functioning and triggering at adjusted setpoints. -
Page 22: Electrical Connections
NOTE: In order to meet the requirements of the Ecodesign Directive 2009/125/EC with regard to efficient system operation, ensure the heat exchangers remain clean at all times. Electrical connections WARNING Isolating switch "On"! Danger of electric shock! Before undertaking any task on electrical equipment, turn off the main power supply to de-energise the unit. -
Page 23: Appendix 1: Wiring Diagrams - Zx Small Units (220-240 V / 1 Ph / 50 Hz)
Appendix 1: Wiring diagrams – ZX Small units (220-240 V / 1 Ph / 50 Hz) Figure 15: Wiring diagram ZXME units AGL_Unit_ZX_Small_E_Rev03... -
Page 24: Figure 16: Wiring Diagram Zxle Units
Figure 16: Wiring diagram ZXLE units AGL_Unit_ZX_Small_E_Rev03... - Page 25 Position Description Cable Description Fan speed controller Fan speed controller power cable Capacitor Capacitor Crankcase heater Crankcase heater cable Fuse 12 A Fuse 3.15 A Compressor motor Compressor power cable Fan motor Fan power cable Main switch Contactor Q11.RC RC suppressor Low-pressure switch Control cable Discharge line...
-
Page 26: Appendix 3: List Of Tables And Figures
Appendix 2: List of tables and figures Tables Table 1: ZX Small refrigeration unit technical data ................3 Table 2: ZX Small refrigeration unit features ..................4 Table 3: Qualified refrigerants and oils ....................5 Table 4: BOM ............................. 5 Table 5: Legend of the P&I diagram for ZXME units................ -
Page 27: Disclaimer
3. Emerson does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any Emerson product remains solely with the purchaser or end user. - Page 28 The Emerson logo is a trademark and service mark of Emerson Electric Co. Emerson Climate Technologies Inc. is a subsidiary of Emerson Electric Co. Copeland is a registered trademark and Copeland Scroll is a trademark of Emerson Climate Technologies Inc.. All other trademarks are property of their respective owners.
