PG-3 & PG-10A
Paging Amplifiers
PG-3
PG-10A
Aiphone Communication Systems • 1700 130th Ave. N.E. • Bellevue, WA 98005
(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • www.aiphone.com
3 Watt Intercom Paging Amplifier:
• Compatible with LEF, LAF-C and NEM systems
• Does not require a separate paging adaptor
• 20 and AUX inputs
• 2 and 8 outputs
• Built-in volume control
• 12V DC powered
SPECIFICATIONS:
Power Source:
Power Output:
Distortion:
Inputs:
Outputs:
Dimensions (HxWxD):
10 Watt Paging Amplifier:
• Used for background music on the NEM system (w/ NB-U)
• Compatible with any Aiphone system that supports paging
• Can be used as a standard paging amplifier
• 25V and 70V outputs
• Circuit breaker helps protect against surges and shorts
• Shelf or wall mounted
SPECIFICATIONS:
Power Source:
Power Output:
Input:
Distortion:
Frequency Response:
Power Consumption:
Dimensions (HxWxD):
- 70 -
Accessories
12V DC
3 Watts
Less than 1% at 1,000Hz, 1 Watt output
Input 1: 10K , 100mV
Input 2: 20 , 600mV
2 and 8
4-1/16" x 2-1/4" x 1-3/8"
110V AC
10 Watt, 25V and 70V Balanced
100mV for rated output
Less than 3% at 1,000Hz, rated output
+/- 3db, 100 - 15,000 Hz
30 Watts
9-11/16" x 3-1/16" x 6"
