o Type a message: "Hello, world".
o What you type should show up under "Transmit" in the window.
o Select "Send" from the menu.
o The message will appear in red under "Received".
o To open a different port, either select "File->New" or "Disconnect" from the menu.
• readlb.exe
• writelb.exe
• readreg.exe
• writereg.exe
• send.exe
• flushrx.exe
• flushtx.exe
• getbufs.exe
• setbufs.exe
• getclock.exe
• getclock2.exe
• read_file_hdlc.exe user program to read hdlc frames from a port and stuff them to a
• sendfile.exe
• setchecktimeout.exe
• setfs6131clock.exe user program that sets the fs6131 clock generator which is only
• setrfi.exe
• setrirq.exe
• settirq.exe
• settfi.exe
• simuln200.exe
• st_tt.exe
• status.exe
user program to read a SuperFastcom special register
user program to read a SuperFastcom special register
user program to read a 20534 register
user program to write to a 20534 register
user program that opens a file and sends it through port 0
user program to flush the SuperFASTCOM receiver/buffers
user program to flush the SuperFASTCOM transmitter/buffers
user program to get buffering/descriptor parameters for a port
user program to set buffering/descriptor parameters for a port
user program to get the current clock generator settings
user program to get the current program clock generator settings
file
user program to send a file out a SuperFastcom port
user mode function to set the timeout timer in the driver
that checks for frames to be returned or sent
valid if you have an extended temperature card with fs6131's on it
user program to mask/unmask the frame end interrupt indication for
receive descriptors
user program to set the interrupt rate for receive descriptors
user program to set the interrupt rate for transmit descriptors
user program to mask/unmask the frame end interrupt indication for
transmit descriptors
user program to generate 26 byte hdlc frames simulating an LN200
user program to switch the onboard txclk multiplexer between the
TT output and the ST input
user program to read status from a SuperFastcom port
