CONFIGURATION FOR SuperFASTCOM CABLE ASSEMBLY
The cable provided with your SuperFastcom adapter splits each channel from the DB78 to into
four DB 25 male connectors.
SIGNAL DB25 #
GND
GND
SD-
SD+
RD-
RD+
RTS-
RTS+
CTS-
CTS+
DCD-
DCD+
TT-
TT+
RT-
RT+
ST-
ST+
PRGCLK-
PRGCLK+
CHANNEL 1
1 58
7 68
2 70
14 50
3 73
16 53
4 71
19 51
5 74
13 54
10 76
8 57
11 69
24 52
9 72
17 56
12 75
15 55
23 77
20 78
DB78 PIN NUMBER
CHANNEL 2 CHANNEL 3
38
29
13
32
36
17
33
14
18
37
31
12
30
11
16
35
34
15
N/A
N/A
CHANNEL 4
9 48
10 49
22 62
2 46
6 65
26 42
3 63
23 45
27 66
7 41
8 40
28 60
1 61
21 47
25 64
5 43
4 67
24 44
N/A N/A
N/A N/A
