Attach the keyboard tray to the mounting pillar

1. Affix the small pressure pads (8) onto the reverse side of the keyboard tray (2) in the
areas indicated in the diagram.
2. Use the M4*55 Allen wrench (12) to insert two M6*8 screws (13) into the top two
holes on the keyboard tray and then the mounting pillar (7).
3. Turn the Allen wrench clockwise to tighten the screws.
Warning! Do not over-tighten the screws. (tightening torque is 1.5 Nm)
Instruction manual
8
12
2
9
13
7
