Attach the back plate to the keyboard tray

1. Line up the top four holes on the back plate (3) with the four holes on the keyboard
tray (2) so that the bottom two holes on the back plate are hanging over the edge
of the keyboard tray. Depending on your preference, you can attach the back plate
centered on the keyboard tray or off-centered to the right or left.
2. Use the M4*55 Allen wrench (12) to insert four M6*12 screws (14) into the back
plate and then the keyboard tray.
3. Turn the Allen wrench clockwise to tighten the screws.
Warning! Do not over-tighten the screws. (tightening torque is 1.5 Nm)
Example of the back plate attached:
Instruction manual
14
2
8
12
3
