Sit-Stand Desktop Workstation
- 35" Work Surface
ARMSTSL
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/ARMSTSL.
Manual Revision: 10/11/2017
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com ARMSTSL
Summary of Contents for StarTech.com ARMSTSL
- Page 1 Sit-Stand Desktop Workstation - 35” Work Surface ARMSTSL *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
- Page 3 Warning statements Avertissements Do not exceed the weight capacity of this product. Overloading this product might result in injury Ne dépassez pas la capacité pondérale du produit. Une surcharge du produit peut entraîner des blessures or property damage. ou des dommages matériels. Do not allow any part of your component cables to get caught between moveable parts, as it could Veillez à...
-
Page 4: Table Of Contents
Table of Contents Warnings ..............................i Product dimensions ................1 Weight capacity ............................2 Package contents ...................3 Raise or lower the ARMSTSL ..............3 Add equipment to the ARMSTSL ............4 Adjust the tension of the ARMSTSL.............6 Reposition the keyboard tray ...............7 Technical support ...................8 Warranty information ................8... -
Page 5: Product Dimensions
Product dimensions 160 mm (6.3”) 22 mm (0.9”) 15 mm (0.6”) 560 mm (22.0”) 15 mm (0.6”) 422 mm (16.6”) Instruction manual... -
Page 6: Weight Capacity
900 mm (35.4”) 624 mm (24.6”) 530 mm (20.9”) 666 mm (26.2”) 265 mm (10.4”) 130 mm (5.1”) 173 mm 680 mm (6.8”) (26.8”) Weight capacity 0 to 12.7 kg (0 to 28 lb.) 0 to 5 kg (0 to 2.3 lb.) Instruction manual... -
Page 7: Package Contents
• 1 x small hex key • 1 x large hex key Raise or lower the ARMSTSL Warning! Before you move the workstation up or down, make sure that the equipment mounted on the workstation is secure. If your equipment is not stable, it could fall off of the workstation as you move it and the equipment could be damaged. -
Page 8: Add Equipment To The Armstsl
Add equipment to the ARMSTSL Warning! If you use a monitor arm with the ARMSTSL, make sure that you don’t position the monitors beyond the edge of the desk surface. If you extend the monitors past the desk surface, you could create a tipping hazard. Make sure that you lower the ARMSTSL to its lowest position before you add equipment to it, distribute the weight across the ARMSTSL evenly, and don’t extend the monitors beyond the edge of the... - Page 9 5. Position your equipment cables so that they run through the loops located at the back of the ARMSTSL. (figure 3) 6. If necessary, reposition the keyboard tray. For more information about how to do this, see the “Reposition the keyboard tray” section of the manual.
-
Page 10: Adjust The Tension Of The Armstsl
1. Carefully remove all of the equipment from the ARMSTSL. 2. Raise the ARMSTSL to the highest position. 3. To adjust the tension of the ARMSTSL, use the large hex key to turn the adjustment screw clockwise or counterclockwise. (figure 4) 4. -
Page 11: Reposition The Keyboard Tray
Reposition the keyboard tray 1. Remove the equipment from the keyboard tray. 2. Raise the ARMSTSL to a position that enables you to access the underside of the keyboard tray. 3. Use the small hex key to remove the two sets of six screws from the underside of the keyboard tray. -
Page 12: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 13 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
