- Page 2 We apologize for and bolts. in the nuts. way in. the inconvenience. For more tips, please visit the link below: https://totemmaker.net/blog/totem-mechanics-for-beginners/...
-
Page 3: Part List
4x Nylon Standoff M3x8 2x C-Bracket 4x Strip Bracket 75 mm 6x Nylon Spacer 4 mm 2x Nylon Spacer 8 mm 2x DC Motor Hub 2x DC Motor Bracket 1x Battery Case with Switch 1x DC Motor 1x Totem Screwdriver 1x Totem Wrench... - Page 4 2x Beam 90 mm 5x Nut M3 6x10 # indicates number of circular hole. indicates counting direction. 2x Bolt M3x10 1x DC Motor Bracket...
- Page 5 1x DC Motor 2x Bolt M3x10 1x DC Motor Bracket # indicates number of circular hole. indicates counting direction. 2x Bolt M3x25 2x Nut M3 6x10...
- Page 6 Tighten the bolts firmly. 2x Beam 40 mm 2x Bolt M3x35 2x Nylon Spacer 4 mm 4x Nut M3 6x10 2x Bolt M3x25...
- Page 7 2x DC Motor Hub 2x Bolt M3x25 Tighten the Repeat this step twice. bolt firmly. 2x Nut M3 6x10 2x Bolt M3x6 1x Step 6 Assembly 1x Step 7 Assembly Screw bolt with strength as the hub’s hole is tight fit.
- Page 8 Do not use much force when tightening Nylon Standoffs. 2x Nylon Standoff 2x Beam 90 mm 1x C-Bracket 3x Nut M3 6x10 Use wrench for Nylon Standoffs. 1x Bolt M3x6 1x Step 8 Assembly 1x Step 9 Assembly # indicates number of circular hole.
- Page 9 1x Strip Bracket 1x Bolt M3x10 1x Nylon Spacer 4 mm 1x Lock Nut M3 Do not use much force when tightening Bolt into Standoff. Use wrench for Lock Nut. Do not over-tighten Strip Bracket. Bracket must be slightly loose.
- Page 10 1x Strip Bracket 1x Nylon Spacer 4 mm 1x Nylon Spacer 8 mm 1x Lock Nut M3 1x Bolt M3x10 Do not over-tighten Strip Bracket. Bracket must be slightly loose. Use wrench for Do not use much Lock Nut. force when tightening Bolt into Standoff.
- Page 11 Do not use much force when tightening 2x Nylon Standoff 2x Beam 90 mm Nylon Standoffs. 1x C-Bracket 3x Nut M3 6x10 1x Bolt M3x6 Use wrench for Nylon Standoffs.
- Page 12 1x Step 12 Assembly 1x Step 13 Assembly # indicates number of circular hole. indicates counting direction.
- Page 13 1x Strip Bracket 1x Bolt M3x10 Do not use much 1x Nylon Spacer 4 mm 1x Lock Nut M3 force when tightening Bolt into Standoff. Use wrench for Do not over-tighten Lock Nut. Strip Bracket. Bracket must be slightly loose.
- Page 14 1x Strip Bracket 1x Nylon Spacer 4 mm 1x Nylon Spacer 8 mm 1x Lock Nut M3 Do not use much 1x Bolt M3x10 force when tightening Bolt into Standoff. Use wrench for Lock Nut. Do not over-tighten Strip Bracket. Bracket must be slightly loose.
- Page 15 1x Beam 90 mm 2x Beam 40 mm 5x Bolt M3x6 5x Nut M3 6x10 2x 2-Hole Simple 1x 2-Hole 45 Simple Bracket Bracket # indicates number of circular hole. indicates counting direction.
- Page 16 2x 2-Hole 45 Bracket 1x Bolt M3x8 1x Nut M3 6x10 # indicates number of circular hole. indicates counting direction.
- Page 17 1x Bolt M3x6 1x Battery Case with Switch Connect motor with battery switch.
- Page 18 Loosen Lock Nuts (if needed, on both sides) if motor cannot move legs. Tighten Lock Nuts (if needed, on both sides) if legs are too wobbly. Woohoo! Your Giraffe is now alive and ready to play.
-
Page 19: Battery Information
KEEP THIS INTRUCTION MANUAL AND THE PRODUCT BOX AS IT CONTAIN IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to the continuous product improvement, the pictures on this manual may differ slightly from the actual product. Please adhere to actual product instead. Totem Maker names and logos are registered trademarks. All rights reserved. WARNING: www.totemmaker.net...
