- Page 2 We apologize for and bolts. way in. the inconvenience. For more tips, please visit the link below: https://totemmaker.net/blog/totem-mechanics-for-beginners/...
-
Page 3: Part List
3x Lock Nut M3 47x Nut M3 6x10 2x Nylon Spacer 4 mm 1x Nylon Spacer 8 mm 2x DC Motor Hub 2x DC Motor Bracket 1x Battery Case with Switch 1x DC Motor 1x Totem Screwdriver 1x Totem Wrench... - Page 4 2x 2-Hole 1x Beam 40 mm Simple Bracket 3x Nut M3 6x10 1x Bolt M3x6 2x Beam 40 mm 3x Bolt M3x6 6x Nut M3 6x10 1x Step 1 Assembly 1x 2-Hole Simple Bracket...
- Page 5 2x 2-Hole 1x Beam 40 mm Simple Bracket 2x Nut M3 6x10 1x Bolt M3x6 2x Beam 40 mm 3x Bolt M3x6 3x Nut M3 6x10 1x Step 3 Assembly 1x 2-Hole Simple Bracket...
- Page 6 2x Bolt M3x12 1x Bolt M3x16 1x Step 2 Assembly 1x Step 4 Assembly...
- Page 7 2x DC Motor Bracket 2x Nut M3 6x10 2x Bolt M3x10 2x Bolt M3x25 1x DC Motor...
- Page 8 1x Beam 90 mm 1x Beam 40 mm 2x Bolt M3x6 1x L-Twisted Bracket 2) Screw this 1) Screw this bolt secondly. bolt fi rst. 4x Nut M3 6x10...
- Page 9 1x Beam 40 mm 2x Board Triangle 4x Bolt M3x6 1x Bolt M3x20 1x L-Twisted 1x 2-Hole 45 Mirror Bracket Simple Bracket 1x Nylon Spacer 8 mm 1x Lock Nut M3 2x Nut M3 6x10 1x Step 7 Assembly Do not over tighten the Lock Nut.
- Page 10 1x Bolt M3x6...
- Page 11 # indicates number of circular hole. indicates counting direction. 2x Beam 40 mm 2x Board Triangle 2x Bolt M3x6 2x Bolt M3x12 2) Screw this bolt secondly. 4x Nut M3 6x10 1) Screw this bolt fi rst.
- Page 12 2x Beam 40 mm 5x Nut M3 6x10 2x Bolt M3x6 1x Bolt M3x8 1x 2-Hole Simple 2x 2-Hole 45 Bracket Simple Bracket 2x Beam 40 mm 4x Nut M3 6x10 1x 2-Hole 45 4x Bolt M3x6 Simple Bracket...
- Page 13 2x Bolt M3x6 # indicates number of circular hole. indicates counting direction. 2x DC Motor Hub 2x Nut M3 6x10 Tighten the bolt fi rmly. 2x Bolt M3x25 Repeat this step twice.
- Page 14 1x Beam 90 mm 2x Beam 40 mm 4x Bolt M3x6 1x C-Bracket 4x Nut M3 6x10 1x 2-Hole Simple Bracket Top of bracket has # indicates number to be at the of circular hole. 1x 3-Hole 90 Bracket 1x Nylon Spacer 4 mm same level indicates counting as top of...
- Page 15 1x Beam 90 mm 2x Beam 40 mm 4x Bolt M3x6 1x C-Bracket 4x Nut M3 6x10 1x 2-Hole Simple Bracket Top of # indicates number bracket has of circular hole. to be at the 1x 3-Hole 90 Bracket 1x Nylon Spacer 4 mm indicates counting same level direction.
- Page 16 1) Screw bolts half way in DC Motor Hubs. 2x Bolt M3x6 When screwing bolts, use strength as the hubs holes are tight fi t. 2) Mount hubs on motors’ schafts. To do so, 3) Finish tightening turn the hub accordingly so that its hole goes the bolts.
- Page 17 Make sure 1x Battery Case with Switch these brackets are in place. Connect motor with battery switch. Optional step: Bend the neck to make the T-Rex look more realistic.
- Page 18 Loosen Lock Nuts (if needed, on both sides) if motor cannot move legs. Tighten Lock Nuts (if needed, on both sides) if legs are too wobbly. Woohoo! Your T-Rex is now alive and ready to play.
-
