  • Page 2 We and bolts. way in. apologize for the inconvenience. For more tips, please visit the link below: https://totemmaker.net/blog/totem-mechanics-for-beginners/...

  • Page 3: Part List

    PART LIST 224x M3x6 mm Bolt M3x25 mm Bolt Washer 8/1 mm M3 Nylon L-Twisted Bracket Spider foot A Upper Gear Hub Lower Gear A M3x8 mm Bolt M3x45 mm Bolt Washer 9/0.8mm M3 3-Hole Bracket Spider foot B Lower Gear Hub Lower Gear B M3x10 mm Bolt Lock Nut M3...
  • Page 4 PART LIST BEAMS: 2 cm 3 cm 4 cm 5 cm 24 x RoboBoard X4 3x18650 Li-ion pack 6 cm 18 x 7 cm STRIP BRACKETS: 9 cm 16 x 10 cm 11 cm 13 cm Zip Tie 25 mm 3 cm/6H 17 cm 3.5 cm/7H...
  • Page 5 Cutting 40 cm Beams 17 cm 17 cm 6 cm 13 cm 9 cm 9 cm 9 cm 11 cm 9 cm 5 cm 5 cm 5 cm 5 cm 6 cm 9 cm 6 cm 6 cm 7 cm 6 cm 10 cm 9 cm...
  • Page 6 PART 1 Nut M3 6x6 5 cm Beam M3x8 mm Bolt M3x8 mm Bolt 9 cm Beam M3x10 mm Bolt 2-Hole Simple Bracket 4.5 cm/9 Holes Strip Bracket M3x16 mm Bolt 7.5 cm/15 Holes Strip Bracket 7.5 cm/15 Holes Strip Bracket Nut M3 6x6 Lock Nut M3...
  • Page 7 Nut M3 6x6 M3x8 mm Bolt Single Side Filler 2-Hole 45 Simple Bracket 5 cm Beam Repeat this step 4 times. 4.5 cm/9 Holes Strip Bracket...
  • Page 8 M3x8 mm Bolt Nut M3 6x6 Repeat this step 4 times. 2-Hole Simple Bracket Beam Plug 5 cm Beam...
  • Page 9 M3x16 mm Bolt Repeat this step 4 times. Lock Nut M3...
  • Page 10 Alternatively use a Repeat this step 4 times. socket for 5.5 mm HEX heads to hold the lock nuts. Tip for tightening lock nuts: Here a bolt and a lock nut is used as a hub or bearing in joints between the spider leg parts. They should not be tightened too much, since they must rotate easily.
  • Page 11 M3x10 mm Bolt Repeat this step 4 times. Spider foot A PART 1A...
  • Page 12 Nut M3 6x6 M3x8 mm Bolt 2-Hole Simple Bracket Repeat this step 4 times. 9 cm Beam 7.5 cm/15 Holes Strip Bracket...
  • Page 13 Nut M3 6x6 M3x8 mm Bolt Single Side Filler 2-Hole 45 Simple Bracket Repeat this step 4 times. 5 cm Beam 4.5 cm/9 Holes Strip Bracket...
  • Page 14 M3x8 mm Bolt Nut M3 6x6 Repeat this step 4 times. 2-Hole Simple Bracket Beam Plug 5 cm Beam...
  • Page 15 M3x16 mm Bolt Repeat this step 4 times. Lock Nut M3...
  • Page 16 Alternatively use a Do not over-tighten socket for 5.5 mm the lock nuts. HEX heads to hold the lock nuts. Repeat this step 4 times.
  • Page 17 M3x10 mm Bolt Repeat this step 4 times. Spider foot A PART 1B...
  • Page 18 PART 2 Nut M3 6x10 M3x6 mm Bolt M3x6 mm Bolt M3x8 mm Bolt M3x45 mm Bolt Lock Nut M3 2-Hole Simple Bracket Nut M3 6x10 Nut M3 6x6 2-hole Simple C-Bracket Bracket 6 cm Beam 2-Hole 45 L-Twisted L-Twisted Beam Plug Bracket Mirror Bracket...
  • Page 19 M3x8 mm Bolt Nut M3 6x6 M3x6 mm Bolt 2-Hole Simple Bracket Nut M3 6x10 9 cm Beam 3.5 cm/7 Holes Strip Bracket 8 mm Repeat this step 2 times.
  • Page 20 8 mm Nut M3 6x10 M3x8 mm Bolt M3x6 mm Bolt Nut M3 6x6 2-Hole Simple Bracket 9 cm Beam Repeat this step 2 times. 2-Hole 45 Bracket...
  • Page 21 Nut M3 6x10 M3x6 mm Bolt Repeat this step 2 times. 2-Hole Simple Bracket...
  • Page 22 Nut M3 6x6 M3x8 mm Bolt Repeat this step 2 times. Beam Plug...
  • Page 23 Nut M3 6x6 M3x8 mm Bolt Repeat this step 2 times. Beam Plug...
  • Page 24 M3x6 mm Bolt C-Bracket Nut M3 6x10 4 cm Beam Repeat this step 2 times.
  • Page 25 M3x6 mm Bolt C-Bracket Nut M3 6x10 17 cm Beam 17 cm Repeat this step 2 times.
  • Page 26 M3x8 mm Bolt Rocker 3 cm/6 Holes Strip Bracket Repeat this step 8 times.
  • Page 27 45 mm Use pliers or Totem wrench to hold the nut when screwing in the bolt. 45 mm Lock Nut M3 M3x45 mm Bolt Repeat this step 2 times. Rocker Washer...
  • Page 28 Do not overtighten strip brackets. Repeat this step 4 times.
  • Page 29 M3x6 mm Bolt Nut M3 6x10 L-Twisted Mirror Bracket L-Twisted Bracket Repeat this step 2 times.
  • Page 30 M3x6 mm Bolt Repeat this step 2 times. Upper Gear Hub Lower Gear Hub Bearing 8x16x5 Repeat this step 4 times.
  • Page 31 Make sure the blue bearing hubs are positioned correctly. The bearings are in the outer position. See below: 54 mm M3x8 mm Bolt PART 2 Nut M3 6x10...
  • Page 32 PART 3 M3x8 mm Bolt Nut M3 6x10 M3x12 mm Bolt Upper Gear A Upper Gear B M3x25 mm Bolt M3-HEXH 12 mm Bolt Lower Gear A Lock Nut M3 Lower Gear B Washer 9/0.8mm M3 Lower Gear C Metal Nut M3 Lower Gear D Motor Coupler 6 mm 9.5 cm/19 Holes...
  • Page 33 Metal nut helps to press bolt into gear. Insert bolts as deep as possible (min 2 mm). M3-HEXH 12 mm Bolt Metal Nut M3 Lower Gear A Lower Gear B Lower Gear C Lower Gear D...
  • Page 34 Lower Gear A Part 2 Nut M3 6x10 Lower Gear C M3x25 mm Bolt Gear C Bolts (in red) will be diagonally opposite to each other. Gear A Letters “A” and “C” identify the gears, in the middle of the parts. Repeat this step 2 times.
  • Page 35 Letters “A”, “B”, “C”, “D” identify the gears. Gear D Bolts (in red) will be diagonally opposite to each other. Gear B Lower Gear B Nut M3 6x10 Repeat this step 2 times. Lower Gear D M3x25 mm Bolt...
  • Page 36 Gear B Arrows must point to each oth- er on both sides. Gear A Triangles must point at the same direction on both upper gears. Upper Gear A Nut M3 6x10 Repeat this step 2 times. Upper Gear B M3x25 mm Bolt...
  • Page 37 M3x8 mm Bolt Motor Coupler 6 mm 8 mm Repeat this step 2 times.
  • Page 38 Lock Nut M3 Washer 9/0.8mm M3 9.5 cm/19 Holes Strip Brackets Repeat this step 2 times.
  • Page 39 Mount the Lock Nut M3 M3x12 Bolt in the middle hole of the 9.5 cm strip bracket. Washer 9/0.8mm M3 M3x12 mm Bolt 12 mm Repeat this step 2 times. Hole #1 Hole #10...
  • Page 40 Check all links, do not tighten too much. Not too loose either. Ensure smooth rotation when turning gears. PART 3...
  • Page 41 PART 4 4 x Part 1A 4 x Part 1B 2 x Part 3 2 x Part 4 M3x12 mm Bolt M3x45 mm Bolt Lock Nut M3 Upper Arm Washer Nylon Washer 8/1 mm M3 Washer 9/0.8mm M3...
  • Page 42 Part 1A Part 1B Part 1B Part 1A...
  • Page 43 Part 1B 45 mm Part 1A Lock Nut M3 Upper Arm Washer Repeat this step 2 times. Washer 9/0.8mm M3 M3x45 mm Bolt...
  • Page 44 Do not overtighten.
  • Page 45 12 mm M3x12 mm Bolt Lock Nut M3 Repeat this step 2 times. Nylon Washer 8/1 mm M3...
  • Page 46 Part 1A Lock Nut M3 Part 1B M3x45 mm Bolt Upper Arm Washer Washer 9/0.8mm M3 45 mm Repeat this step 2 times.
  • Page 47 Do not overtighten.
  • Page 48 M3x12 mm Bolt Lock Nut M3 Nylon Washer 8/1 mm M3 Do not overtighten. 12 mm Repeat this step 2 times.
  • Page 49 Try spinning the gears with your hands, and check if it has a PART 4 smooth motion. Legs and links should not be too wobbly.
  • Page 50 PART 5 Nut M3 6x10 M3x6 mm Bolt 2-Hole Simple Bracket 6 cm Beam 2-Hole Simple M3x6 mm Bolt Nut M3 6x10 Bracket L-Twisted Bracket C-Bracket L-Twisted Mirror Bracket Repeat this step 4 times. 7 cm Beam 3 cm Beam 6 cm Beam...
  • Page 51 Repeat this step 4 times. M3x6 mm Bolt C-Bracket 3 cm Beam Nut M3 6x10...
  • Page 52 Repeat this step 4 times. M3x6 mm Bolt Nut M3 6x10 2-Hole Simple Bracket...
  • Page 53 M3x6 mm Bolt Nut M3 6x10 Repeat this step 2 times. L-Twisted Mirror 7 cm Beam L-Twisted Bracket Bracket...
  • Page 54 PART 5 Repeat this step 2 times. M3x6 mm Bolt Nut M3 6x10...
  • Page 55 PART 6 Repeat this step 2 times. M3x6 mm Bolt Motor-Plate 37 mm 37 mm DC Motor...
  • Page 56 PART 7 M3x6 mm Bolt Part 5 M3x14 mm Bolt M3x6 mm Bolt Repeat this step 2 times.
  • Page 57 Flat side up Part 6 Repeat this step 2 times. M3x14 mm Bolt...
  • Page 58 Flat side PART 7 M3x6 mm Bolt...
  • Page 59 PART 8 13 cm 9 cm Nut M3 6x10 M3x6mm Bolt 2-Hole Simple Bracket C-Bracket 3-Hole Bracket L-Twisted Mirror Bracket Nylon Standoff 6 cm Beam L-Twisted Bracket M3x8 mm M3x6 mm Bolt Nut M3 6x10 2-Hole Simple Bracket 7 cm Beam 9 cm Beam 11 cm Beam 9 cm Beam...
  • Page 60 Nut M3 6x10...
  • Page 61 3-Hole Bracket M3x6 mm Bolt Nut M3 6x10...
  • Page 62 11 cm 6 cm 6 cm C-Bracket L-Twisted Bracket L-Twisted Mirror Bracket Repeat this step 2 times. M3x6 mm Bolt Nut M3 6x10 6 cm Beam 11 cm Beam...
  • Page 63 Step 4 assembly. Step 4 assembly. M3x6 mm Bolt Nut M3 6x10 Step 4 Assembly...
  • Page 64 M3x6 mm Bolt 2-Hole Simple Bracket Nut M3 6x10...
  • Page 65 M3x6 mm Bolt 2-Hole Simple Bracket Nut M3 6x10 7 cm Beam 9 cm Beam...
  • Page 66 M3x6 mm Bolt Step 7 Assembly Step 6 Assembly...
  • Page 67 Nut M3 6x10...
  • Page 68 PART 8 Nylon Standoff M3x8 mm...
  • Page 69 PART 9 RoboBoard X4 Zip Tie 25 mm M3x6 mm Bolt Zip Tie 25 mm 3x18650 Li-Ion 3x18650 Li-ion pack. Pack.
  • Page 70 M3x6 mm Bolt RoboBoard X4...
  • Page 71 PART 9...
  • Page 72 PART 10 M3x6 mm Bolt M3x6 mm Bolt...
  • Page 73 M3x6 mm Bolt...
  • Page 74 PART 3...
  • Page 75 PART 11 M3x6 mm Bolt Nut M3 6x10 2-Hole Simple Bracket 3-Gole 45 Bracket 2-Hole 45 Bracket Swan 90x45 Repeat this step 4 times. Double Side Filler 2 cm Beam 5 cm Beam 6 cm Beam 7 cm Beam 10 cm Beam Nut M3 6x10 M3x6 mm Bolt 2-Hole 45 Bracket...
  • Page 76 Repeat this step 2 times. M3x6 mm Bolt Nut M3 6x10 Double Side Filler 5 cm Beam 10 cm Beam 2-Hole 45 Bracket...
  • Page 77 Repeat this step 2 times. M3x6 mm Bolt...
  • Page 78 Nut M3 6x10 7 cm Beam M3x6 mm Bolt...
  • Page 79 Repeat this step 2 times. Nut M3 6x10 6 cm Beam M3x6 mm Bolt 2-Hole Simple Bracket Swan 90x45...
  • Page 80 M3x6 mm Bolt PART 11...
  • Page 81 Nut M3 6x10 PART 12 M3x6 mm Bolt Nut M3 6x10...
  • Page 82 Part 11...
  • Page 83 M3x6 mm Bolt...
  • Page 84 M3x6 mm Bolt PART 12...
  • Page 85 CONNECTING ELECTRONICS...

  • Page 86: Battery Recharging

    BATTERY RECHARGING When the battery is dead, connect the power adapter to the board. - When the LED is off, the battery is fully charged. - When the LED is on, the battery is charging. - When the LED is blinking, the battery is not connected.
  • Page 87 ROBOBOARD X4...

  • Page 88: Consumer Information

    The product is made of complex electronic circuit and electronic components, do not disassemble, or modify the circuit board. BATTERY SAFETY INFORMATION: • This Black Spider is designed to work with provided Totem Battery (3S Li-Ion 11.1V 2200mAh battery with JST-VH connector) and provided Totem power adapter (30W, 15V, 2A, 5.5/2.0 mm center-positive connector DC adapter). •...

  • Page 89: Battery Charging

    The charger will show a red LED light when charging the battery. When the battery is fully charged, the red LED light turns off. Due to the continuous product improvement, the pictures on this manual may differ slightly from the actual product. Please adhere to actual product instead. Totem Maker names and logos are registered trademarks. All rights reserved. www.totemmaker.net Totem Technology, UAB Sauletekio al.
