Summary of Contents for Totem Dog
- Page 2 We apologize for We apologize for and bolts. and bolts. way in. way in. the inconvenience. the inconvenience. For more tips, please visit the link below: For more tips, please visit the link below: https://totemmaker.net/blog/totem-mechanics-for-beginners/ https://totemmaker.net/blog/totem-mechanics-for-beginners/...
-
Page 3: Part List
4x Strip Bracket 75 mm 6x Nylon Spacer 4 mm 2x Nylon spacer 8 mm 4x Nylon Standoff M3x8 2x DC Motor Hub 2x DC Motor Bracket 1x DC Motor 1x Battery Case with Switch 2x Dog Eye 1x Totem Screwdriver 1x Totem Wrench... - Page 4 2x Beam 90 mm 5x Nut M3 6x10 2x Bolt M3x10 1x DC Motor Bracket...
- Page 5 2x Bolt M3x10 1x DC Motor 1x DC Motor Bracket 2x Bolt M3x25 2x Nut M3 6x10...
- Page 6 3x Beam 40 mm 5x Nut M3 6x10 1x Bolt M3x6 2x Bolt M3x35 Tighten the bolts fi rmly. 1x 2-Hole 45 Simple 2x Nylon Spacer 4 mm Bracket 2x Bolt M3x25...
- Page 7 2x Nut M3 6x10 2x DC Motor Hub 2x Bolt M3x25 Repeat this step twice. Tighten the bolts fi rmly.
- Page 8 Screw bolt with strength as Screw bolt with strength as the hub’s hole is tight fi t. 2x Bolt M3x6...
- Page 9 Repeat this step twice. 2x Beam 60 mm 2x Beam 20 mm 4x Bolt M3x6 6x Nut M3 6x10 Do not use much force when tightening force when tightening 2x 2-Hole Simple 2x Nylon Standoff Nylon Standoff s. Bracket # indicates number of circular hole.
- Page 10 1x Strip Bracket 1x Bolt M3x10 1x Nylon Spacer 4 mm 1x Lock Nut M3 Do not use much force when tightening force when tightening Bolt into Standoff . Do not over-tighten Strip Bracket. Bracket must be slightly loose. must be slightly loose.
- Page 11 1x Bolt M3x10 1x Nylon Spacer 4 mm 1x Nylon Spacer 8 mm 1x Lock Nut M3 Do not over-tighten 1x Strip Bracket Strip Bracket. Bracket must be slightly loose. must be slightly loose. Do not use much force when tightening force when tightening Bolt into Standoff...
- Page 12 Do not use much force when tightening Nylon Standoff s. Nylon Standoff s. 2x Beam 60 mm 2x Beam 20 mm 4x Bolt M3x6 6x Nut M3 6x10 Repeat this step twice. 2x 2-Hole Simple 2x Nylon Standoff Bracket # indicates number of circular hole.
- Page 13 1x Strip Bracket 1x Bolt M3x10 1x Nylon Spacer 4 mm 1x Lock Nut M3 Do not use much force when tightening force when tightening Bolt into Standoff . Do not over-tighten Strip Bracket. Bracket must be slightly loose. must be slightly loose.
- Page 14 1x Bolt M3x10 1x Nylon Spacer 4 mm 1x Nylon Spacer 8 mm 1x Lock Nut M3 1x Strip Bracket Do not use much force when tightening force when tightening Bolt into Standoff . Do not over-tighten Strip Bracket. Bracket must be slightly loose.
- Page 15 2x Nut M3 6x10 2x Bolt M3x6 2x Board Triangular...
- Page 16 1x Nut M3 6x10 1x Bolt M3x6 1x Board Triangular...
- Page 17 1x Nut M3 6x10 1x Bolt M3x6 1x Board Triangular...
- Page 18 1x Bolt M3x6 2x Bolt M3x8 2x Board Triangular 2x Lock Nut M3 1x 2-Hole 90 Bracket...
- Page 19 2x Beam 40 mm 3x Bolt M3x6 4x Nut M3 6x10 1x 2-Hole Simple Bracket 1x 2-Hole 45 Simple Bracket...
- Page 20 1x Bolt M3x6...
- Page 21 1x Bolt M3x6 Connect motor with battery switch. 1x Battery case 2x Googly Eyes with a Switch Glue Googly Eyes on top of Dog’s head.
- Page 22 Loosen Lock Nuts (if needed, on both sides) if motor cannot move legs. Tighten Lock Nuts (if needed, on both sides) if legs are too wobbly. Woohoo! Your Puppy is now alive and ready to play.
-
Page 23: Battery Information
KEEP THIS INTRUCTION MANUAL AND THE PRODUCT BOX AS IT CONTAIN IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to the continuous product improvement, the pictures on this manual may diff er slightly from the actual product. Please adhere to actual product instead. Totem Maker names and logos are registered trademarks. All rights reserved. WARNING: WARNING: www.totemmaker.net...
