TDI4000 FAQ

WH AT IS A HE AT PU M P DRY ER?

In simple terms a heat pump dryer is a type of condenser dryer. Heat pump dryers are very energy efficient, as they recycle heat in the

process of extracting moisture, resulting in high energy efficiency.

Thanks to their gentle heat, and highly-efficient drying action, heat pump dryers have been a popular eco-friendly option for many years.

H OW A H E AT PU M P T UM BL E D RY ER WORK S:

A heat pump dryer passes hot air over your clothes to collect

moisture and dry them. This same air then goes through an

evaporator, where the moisture is condensed and collected in

the water tank. Where other types of dryers simply blow hot

air on your clothes, heat pump dryers use a more sophisticated

Recycled hot air

energy-efficient heat exchange system to conserve and recycling

Water Tank

the air. This allows the dryer to function at a much lower drying

temperature over extended drying times making it gentler on

Fan

your clothes.

Used hot air & moisture

Heat Exchanger & Compressor

www.caple.co.uk

For more information visit www.caple.co.uk

Table of Contents

Need help?

Do you have a question about the TDI4000 and is the answer not in the manual?

Page 1 Water Tank the air. This allows the dryer to function at a much lower drying temperature over extended drying times making it gentler on your clothes. Used hot air & moisture Heat Exchanger & Compressor www.caple.co.uk For more information visit www.caple.co.uk...
Page 2 Figure 1 If a floor to worktop door is being used ventilation is required in the door as detailed in the instruction manual and in the Min. Ø127mm image below: 93mm Min. Ø127mm 93mm www.caple.co.uk For more information visit www.caple.co.uk...
Page 3 If the laundry is not drying check that the filter is not clogged. Clogged un-cleaned filters increase the drying time, energy consumption and can cause damage. If you clean the filters with water, it is important to dry them before using. www.caple.co.uk For more information visit www.caple.co.uk...
Page 4 Clean filters before every cycle. Overloading or a bulk load can Lock the levers by turning them clockwise. lead to door opening. In this case reduce the load capacity to continue drying cycle. Refit the kick plate. www.caple.co.uk For more information visit www.caple.co.uk...
Page 5 Insufficient air circulation in the room may increase the drying time, please ensure is well ventilated. Insufficient air circulation in the room may increase the drying time, please ensure is well ventilated. is well ventilated. www.caple.co.uk For more information visit www.caple.co.uk...
