- Page 1 Instruction Manual Original Manuel d’instructions Traduction Manual de instrucciones Traducción Manuale di Istruzioni Traduzione 使用手冊 翻譯 1WMPD4002909B...
-
Page 3: Table Of Contents
UM-102 Digital Sphygmomanometer Instruction Manual Contents Dear Customers ................2 Preliminary Remarks ................. 3 Notes for Proper Use ................. 4 Parts Identification ................7 Symbols ..................... 8 Using the Monitor ................9 Measurements ................. 12 Useful Features ................13 Troubleshooting ................14 Maintenance .................. -
Page 4: Dear Customers
1. Dear Customers Congratulations on purchasing a state-of-the-art A&D sphygmomanometer, one of the most advanced monitors available on the market today. Designed for ease of use and accuracy. We recommend that you read through this manual carefully before using this device for the first time. Intended User: This device is designed to be used by people who can measure blood pressure by... -
Page 5: Preliminary Remarks
2. Preliminary Remarks Compliance This device conforms to the European Directive 93/42 EEC for Medical Products. This is made evident by the mark of conformity. (0123: The reference number to the involved notified body) Definitions Systolic Blood Pressure Diastolic Blood Pressure Pulse Exhaust This means “releasing the cuff air as soon as possible”. -
Page 6: Notes For Proper Use
Blood Pressure Measurement Do not use on patients with blood flow disorders. The user should stop using the device if there is an abnormality, such as the patient feeling excessive arm pain, and remove the cuff to protect the patient. Contraindications Do not use the device in an ambulance or air ambulance. - Page 7 Before Use Make sure that the device works correctly and that measurement values are accurate. Make sure that the cuff and air hoses are properly connected. Check and maintain the cleanliness of the parts in direct contact with the patient. Avoid placing the device near a strong magnetic field or static electricity.
- Page 8 Periodic Maintenance This device is a precision instrument and contains electronic circuitry. Please check all functions periodically. Contact your nearest A&D authorized dealer for official calibration/check-up, according to your local regulations. Used equipment, parts and batteries are not treated as ordinary household waste, and must be disposed of according to the applicable local regulations.
-
Page 9: Parts Identification
4. Parts Identification Main Body and Accessories Cuff connector Pressure bar display Numerical display MARK button START/STOP button Air hose Exhaust valve Rubber bulb Cuff 1.5V Batteries x 2 Instruction manual (LR6 or AA) Function START/STOP Turns on or off the device. Button During measurement .. -
Page 10: Symbols
5. Symbols Symbols Function / Meaning Recommended Action Standby and Turn the device on Pressure value holding and MARK lifetime counter Battery installation guide Serial number Date of manufacture Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. -
Page 11: Using The Monitor
6. Using the Monitor Installing / Changing the Batteries 1. Remove the battery cover. 2. Insert a new set of batteries into the battery compartment as shown. Make sure the polarities (+) and (-) are correct. Use only LR6, AA or equivalent batteries. - Page 12 2. Insert the air hose plug to the air hose of the cuff. Air hose plug Air hose (cuff) 3. Connect the air hose plug of the cuff to Air hose plug the air hose socket of the main body. (cuff) Air hose socket (main body)
- Page 13 Symbols that are printed on the cuff Symbols Function / Meaning ▲ INDEX Proper fit range Artery position mark ▼ ARTERY Instructions to the patient THIS SIDE TO PATIENT Catalog number Lot number Cuff size 22 cm to 32 cm ADULT Cuff size 41 cm to 50 cm Cuff size 31 cm to 45 cm...
-
Page 14: Measurements
7. Measurements 1. Place the cuff on the arm (preferably the left arm). Keep the patient still during measurement. At heart level 2. Press the button. START/STOP START/STOP When the button is pressed, all START/STOP of the display symbols will appear for about one second. -
Page 15: Useful Features
START/STOP START/STOP power. Note: Model UM-102 has an automatic power-off function. Allow at least three minutes between measurements on the same person. 8. Useful Features Measurement with MARK Button You can put a marker at a certain pressure value... -
Page 16: Troubleshooting
9. Troubleshooting Problem Possible Reason Recommended Action Nothing appears Batteries are empty. Replace all batteries with new ones. in the display, Reinstall the batteries with the Battery polarities even when the negative and positive ends matching are not in the correct power is turned those indicated in the battery position. -
Page 17: Technical Data
Enclosure accessories Internal parts General electronic components Batteries Alkaline battery 11. Technical Data Model UM-102 Measurement method By applying pressure, enabling the determination of blood pressure by the auscultatory method. Measurement range Numerical display Pressure: 0 - 300 mmHg English... - Page 18 Small adult cuff 16 cm to 24 cm CUF-KW-SS SS cuff 12 cm to 17 cm Rubber bulb unit Catalog Number UM-102-10 Connector and Plugs for cuff replacement Catalog Number UM-102-11 Note: Specifications are subject to change without prior notice. English...
- Page 19 EMD Technical Data Battery-operated Blood Pressure Monitor Medical Electrical Equipment needs special precautions regarding EMD and needs to be installed and put into service according to the EMD information provided in the following. Portable and mobile RF communication equipment (e.g. cell phones) can affect Medical Electrical Equipment.
- Page 20 MEMO English...
- Page 21 A&D Company, Ltd. 1-243 Asahi , Kitamoto-shi, Saitama 364-8585, JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 Emergo Europe B.V. Prinsessegracht 20, 2514 AP The Hague, The Netherlands Tel: [31] (70) 345-8570 Fax: [31] (70) 346-7299 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420...
