Setting up the machine ������������������������������������������������������������������������������������������� Filling the bean container ����������������������������������������������������������������������������������������� Determining the water hardness ��������������������������������������������������������������������������������� First-time use ��������������������������������������������������������������������������������������������������������� Managing your Z10 – the JURA Cockpit ����������������������������������������������������������������������� Connecting milk ����������������������������������������������������������������������������������������������������� Connecting the Cool Control milk cooler wirelessly �������������������������������������������������������� Establishing a WiFi connection ����������������������������������������������������������������������������������...
Page 3
Cleaning the bean container ������������������������������������������������������������������������������������� 8 Display messages ������������������������������������������������������������������������������������������������� 9 Troubleshooting ��������������������������������������������������������������������������������������������������� 10 Transport and environmentally friendly disposal �������������������������������������������������������� Transport / Emptying the system ������������������������������������������������������������������������������ Disposal �������������������������������������������������������������������������������������������������������������� 11 Technical data ������������������������������������������������������������������������������������������������������� 12 Index ������������������������������������������������������������������������������������������������������������������ 13 JURA contact details / Legal information �������������������������������������������������������������������...
Replace a damaged plug-in mains cable with an original JURA mains cable� Unsuitable mains cables may result in consequential damage� Only permit authorised JURA service centres to carry out repairs to the machine and the permanently connected mains cable.
Page 8
Q if you are going to be absent for a longer period of time and remove the mains plug from the power socket� Only use original JURA maintenance products� Use of products that are not explicitly recom- mended by JURA could damage your Z10�...
2 For your safety Danger of electric Water conducts electricity. Do not bring water shock and electricity into contact with one another: Never touch the mains plug with wet hands� Do not immerse the Z10 and/or mains cable in water� Do not put the Z10 or any individual parts in the dishwasher�...
3 Preparing and using for the first time 3 Preparing and using for the first time Operation with touchscreen display and Rotary Switch You can operate your Z10 in two ways: Your Z10 has a touchscreen display� Tap or swipe the display to trigger an action�...
3 Preparing and using for the first time Fill the bean container with coffee beans and close the aroma preservation cover� Determining the water When you use the machine for the first time, you must set the water hardness hardness�...
Page 12
3 Preparing and using for the first time E If you do not know the hardness of your water, you must find this out first (see chapter 3 ‘Preparing and using for the first time – Determining the water hardness’)� ...
‘Machine is rinsing’ The start screen is displayed� Your Z10 is ready for use� Managing your Z10 – the JURA Cockpit You can manage your Z10 with the JURA Cockpit. Press the Rotary Switch to open the JURA Cockpit� Symbol Meaning ‘Maintenance’...
Precondition: J�O�E� is installed on your mobile end device and ® you have logged into your home network� The JURA WiFi Connect is inserted into the service socket of your Z10� Press the Rotary Switch� Touch the ‘Machine setting’...
Rotary Switch to take it out of standby mode� E Coffee tastes best served hot� A cold porcelain cup cools the beverage – and impairs the taste� We therefore recommend prewarming the cups� You can purchase a JURA cup warmer from your specialised dealer�...
4 Preparation Aroma Selection You can use Aroma Selection on your Z10 to change the consistency of grind and coffee strength of any product: Example: Espresso with higher coffee strength Place a cup under the dual spout� Touch the ‘Aroma Selection’ symbol (bottom right)� ...
4 Preparation Cold Brew The ‘Cold Brew’ preselection is used to prepare a cold speciality cof- fee� Example: Coffee with ‘Cold Brew’ preselection Fill the water tank with cold water� E You can influence the brewing result: The colder the water in the water tank, the colder the brewed beverage will be�...
4 Preparation Place a glass under the dual spout� Touch ‘Latte macchiato’� The preset amounts of milk and milk foam flow into the glass� E There is a short interval while the hot milk separates from the milk foam� This allows the typical layers of a latte macchiato to form�...
4 Preparation Ground coffee You can choose to use a second coffee variety, for example decaf- feinated coffee, with the filter funnel for ground coffee� Never add more than two level measuring spoons of ground coffee� Use ground coffee which is not ground too finely� Very fine coffee can block up the system so that the coffee only comes out in drips�...
4 Preparation Hot water The Z10 allows you to prepare different variants of hot water: ‘Hot water’ ‘Hot water for green tea’ CAUTION There is a danger of scalding from hot water splashes� Avoid direct contact with the skin� Example: Hot water ...
5 Daily operation 5 Daily operation Switching the machine on and off Place a receptacle under the dual spout� Press the On/Off button � ‘Machine is rinsing’ Your Z10 is switched on or off� E When the machine is switched off, the system is only rinsed if a speciality coffee has been prepared�...
5 Daily operation Maintenance actions Optimal coffee quality depends on many factors� One important prerequisite is regular maintenance of your Z10� Carry out the fol- lowing steps: Maintenance action Daily If necessary Note Empty the drip tray and coffee Always empty the coffee grounds grounds container and rinse with container when the machine is warm water...
‘Units’ Set the unit for the amount of water (ml or oz) ‘Information’ View software version ‘Connect accessory’ Wirelessly connect your Z10 with your JURA app (J�O�E� ) or with the Cool ® Control milk cooler, or disconnect again ‘Display’...
CAUTION If the wrong cleaning agent is used, the machine could be damaged and/or traces could be left behind in the water� Use only original JURA maintenance products�...
7 Maintenance E JURA milk system cleaner is available from specialised dealers� E To clean the milk system, use the container supplied� Precondition: The start screen is displayed� Press the Rotary Switch� Touch c� Touch ‘Clean the milk system’�...
Page 26
Rinse all the parts under running water� If there are severely dried-on milk residues, firstly immerse the individual parts in a solution of 250 ml water and one dosing unit of JURA milk system cleaner� Then rinse the individual parts thoroughly�...
7 Maintenance Fit the cover of the dual spout� Make sure the cover of the dual spout is correctly engaged� Inserting/changing the filter Once the filter cartridge stops working (depending on the water hardness setting), the Z10 will prompt you to change the filter� E Your Z10 no longer has to be descaled if you are using the CLARIS Smart filter cartridge�...
E The cleaning programme lasts approximately 20 minutes� E Do not interrupt the cleaning programme� The quality of cleaning will be impaired if you do so� E JURA cleaning tablets are available from specialised dealers� Precondition: ‘Clean’ is displayed in the Cockpit�...
7 Maintenance Insert a JURA cleaning tablet into the filler funnel� Close the cover of the filler funnel� Touch ‘Next’� ‘Machine is being cleaned’, water flows out of the dual spout repeatedly� ‘Empty coffee grounds container’ Empty the drip tray and coffee grounds container and put them back into the machine�...
Page 30
7 Maintenance Remove and empty the water tank� Completely dissolve 3 JURA descaling tablets in a receptacle holding 600 ml of water� This may take several minutes� Pour the solution into the empty water tank and insert it into the machine�...
Remove the water tank� If you use a CLARIS Smart filter cartridge, remove this� Completely fill the water tank and dissolve 3 JURA descaling tab- lets in it� Leave the water tank with the descaling solution for several hours (e�g�...
8 Display messages 8 Display messages Messages on the start screen Message Cause/Result Action ‘Fill water tank’ The water tank is empty� You cannot Fill the water tank (see chapter 5 prepare any products� ‘Daily operation – Filling the water tank’)�...
Grinder is making a There are foreign objects Contact customer support in your country very loud noise� in the grinder� (see chapter 13 ‘JURA contact details / Legal information’)� ‘Error 2’ ‘Error 5’ If the machine has been Warm the machine at room temperature�...
Page 34
Carefully tighten it using the hexagonal hole on the measuring spoon, turning by no more than a quarter of a rotation� E If you were unable to solve the problem, contact customer support in your country (see chapter 13 ‘JURA contact details / Legal information’)�...
10 Transport and environmentally friendly disposal 10 Transport and environmentally friendly disposal Transport / Emptying the Keep the packaging for your Z10� It should be used to protect the system machine during transport� In order to protect the Z10 from frost during transport, the system must be emptied�...
Interchangeable milk spout CLARIS filter cartridge Smart Frequency band 13�56 MHz (RFID technology) Max� transmission power < 1 mW JURA WiFi Connect Frequency band 2�4 GHz (Bluetooth connection) Max� transmission power < 1 mW JURA WiFi Connect Frequency band 2�4 GHz Max�...
Page 37
12 Index 12 Index Addresses 40 Damage Adjusting the product settings 20 Preventing damage 7 Aroma preservation cover What to do in the event of damage 7 Bean container with aroma preservation Declaration of Conformity 40 cover 5 Descaling Aroma Selection 16 Machine 29 Water tank 31 Display...
Page 39
12 Index Use, First-time 11 Users 6 Water hardness Determining the water hardness 11 Water tank 5 Descaling 31 Filling 21 WiFi 36 WiFi Connect 5, 14 WiFi connection 14 Wireless connection 14, 27, 36...
Page 40
J74488/Z10 /en/202012 (EA/SA/INTA) 13 JURA contact details / Legal information 13 JURA contact details / Legal information JURA Elektroapparate AG Kaffeeweltstrasse 10 CH-4626 Niederbuchsiten Tel� +41 (0)62 38 98 233 E You can find additional contact details for your country at jura.com.
