TE-MDC
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TE-MDC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iBeam TE-MDC

Summary of Contents for iBeam TE-MDC

  • Page 1 TE-MDC Product Manual...
  • Page 2 1. Box Contents a. Camera b. Buzzer c. Camera harness d. Buzzer harness 2. Connections (Orange) parking line wire Remove orange wire from brown connection to remove parking lines.
  • Page 3 3. Mounting Install the camera approximately in the center of the vehicle 4. Specifications Camera Dimensions 39.5 X 28.5 X 32 mm Field of view Detection Range Operating Voltage 8-24V DC Operating Current <200mA / 12V DC Resolution 1280 X 960 (1.2m Pixel) Dynamic range More than 130 dB AV output...
  • Page 4 IMPORTANT If you are having difficulties with the installation of this product, please call out Tech Support line at 386-257-2956. Before doing so, looks over the instructions a second time, and make sure the installation was performed exactly as the instructions are stated. Please have the vehicle apart and ready to perform troubleshooting steps before calling.
