VC520 Pro MS Conference Camera
Quick Installation Guide
Package Contents
Camera Unit
USB 3.0 Cable
Drilling Paper
46.00[1.81]
Ø5.50[Ø0.22]
51.00[2.01]
P/N: 303AU340-AGR
*The power cord will vary depending on the standard power outlet of the country where it is sold.
More Help
For FAQs, technical support, software and user manual download, please visit
Global & European Headquarters:
USA:
https://www.averusa.com/business/support/
Speakerphone Unit
Speakerphone
Cable (Blue)
Quick
Installation
Guide
https://www.aver.com/download-center
Remote Control &
AAA Batteries
3.5 mm Audio
Cable
Two Expansion
Warranty Card
Power Adapter &
Power Cord*
L-Mount
Brackets
Extension Mic
Microphones
Cables (Y/R)
Screws for
Mount
Two

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC520 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for AVer VC520 Pro

Summary of Contents for AVer VC520 Pro

  • Page 1 VC520 Pro MS Conference Camera Quick Installation Guide Package Contents Remote Control & Power Adapter & Camera Unit Speakerphone Unit AAA Batteries Power Cord* Speakerphone 3.5 mm Audio L-Mount Screws for USB 3.0 Cable Cable (Blue) Cable Brackets Mount Quick...
  • Page 2 Overview 1 Status LED 5 RS232 in/out port 2 IR sensor 6 Ethernet port 3 Speakerphone port DC 12V power jack (Blue cable) Kensington Lock 4 USB3.1 Type B port 9 1011 12 Speakerphone port Phone in port (For extended speakerphone Line out port and microphone connection/ Camera port (Blue cable)

  • Page 3: Installation

    Installation Connect the camera to power outlet. Power cord Power adapter Connect the camera to the speakerphone using the included compatible cable. [Note]  Both speakerphone and camera ports are marked in blue.  The back cover of the speakerphone will need to be removed to connect the speakerphone cable.
  • Page 4  The following physical ports will be disabled when initiating Microsoft Teams Room software on the VC520 Pro: RS232, Ethernet. While connecting the VC520 Pro to a Microsoft Teams Room System, the camera will automatically upgrade to the newest FW from Microsoft’s Windows Update Services.

  • Page 5: Remote Control

    Side facial profiles are not detectable. Please refer to the user’s manual for *Function requires AVer PTZApp more details. **Not supported for VC520 Pro  Press and hold the number 1( ) to turn the WDR function on or off.

  • Page 6: Making A Video Call

    Setting up the Camera through the Web Browser VC520 Pro has an Ethernet port for IP streaming and allows administrators to remotely control and set up the camera via an internet access. Moreover, VC520 Pro also supports RTSP and RTMP functions.
  • Page 7 Using AVer IP Finder to find the Camera To find the IP address of your cameras, you can use the AVer IP Finder application. Follow the below steps to find the IP address of camera. Download the IP Finder from https://www.aver.com/download-center...
  • Page 8 Installing AVer PTZApp In AVer PTZApp, user can configure the parameters of the camera. Please go to https://www.aver.com/download-center (Global & European Headquarters) or https://www.averusa.com/business/support/ (USA) to download the AVer PTZApp. After downloading, double-click on the file and follow the on-screen instructions to complete the installation.
  • Page 9 5. Hotkey Control: Enable hotkey control to use keyboard control camera’s movement and backlight. The default is off. A hotkey tip will display when mouse is moved to the PTZ control button in PTZ mode. If the hotkey function is enabled after installing the PTZApp, PTZApp auto launch next time the PC reboots.

  • Page 10: Contact Information

    This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. CAUTION - Risk of explosion if battery is replaced by an incorrect type. - Dispose of used batteries in a safe and proper manner. ©2021 AVer Information Inc. All rights reserved.
