- Page 1 USER MANUAL PROLiNK® 4G LTE Wireless Router PRN3006L Revision 1 (January 2019)
- Page 2 Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.
- Page 3 Preface Revision Date Descriptions 9 January 2019 Initial release...
-
Page 4: Table Of Contents
2 Router Installation...........................5 2.1 System Requirement........................5 2.2 Router Positioning...........................5 2.3 Hardware Setup..........................6 3 Getting Started............................7 3.1 TCP/IP Setup...........................7 3.2 Enter Into Web Configuration......................9 3.3 Enter Into PROLiNK mWiFi......................11 3.4 Setup Wizard..........................13 4 Web Configuration..........................16 4.1 Home.............................17 4.2 WAN..............................18 Connection............................18 Connection Setting..........................19 APN Setting............................19... - Page 5 About..............................34 QOS..............................34 Configuration..........................35 Firmware Upgrade..........................35 Password............................36 Date and Time..........................36 Language............................37 UPnP...............................37 Reboot.............................37 5 Frequently Ask Question (FAQ)......................38 6 Technical Specification.........................40...
-
Page 6: Introduction
PROLiNK® PRN3006L 4G LTE Wireless Router 1 Introduction Packaging Contents Quantity (unit) Item Descriptions PRN3006L LTE Antenna RJ45 Ethernet Cable Power Adapter Quick Installation Guide (QIG) -
Page 7: Product Overview
4G LTE Wireless Router Product Overview PROLiNK® PRN3006L 4G LTE Wireless Router is design to provides with greater speed of data transferring up to 150Mbps support your daily life device requirement such as Laptop, Personal Computer, Smartphone, iPad and other Internet connection devices. Wireless technology implemented on PROLiNK®... -
Page 8: Hardware Overview
LED indicator for Power, 2.4GHz, LAN, Internet and Mobile Signal Antenna LTE Antenna to extend mobile coverage Power Button To switch ON and OFF PRN3006L DC Input To connect with provided power adapter LAN Port Port to connect with client Ethernet port and one of LAN to... -
Page 9: Led Indicator
PROLiNK® PRN3006L 4G LTE Wireless Router LED Indicator Device is OFF Power Green Device is ON 2.4GHz Radio is disabled Wi-Fi Green 2.4GHz Radio is enabled Green Blinking 2.4GHz Client connected LAN Port disconnected Green Blinking LAN Port connected Internet service is not available... -
Page 10: Router Installation
PROLiNK® PRN3006L 4G LTE Wireless Router 2 Router Installation System Requirement In order to setup PRN3006L you would need to ensure the following item in the list is available. • SIM Card of 2FF size (Mini SIM). • Ethernet Cable with RJ45 connector at both end. -
Page 11: Hardware Setup
1. Install 2 units of LTE antenna on the back of PRN3006L. 2. Insert the SIM Card into the slot per the direction shown in the bottom case of the PRN3006L. 3. [Optional – only applicable for PRN3006L with Voice] Connect the PRN3006L’s telephone port to telephone. -
Page 12: Getting Started
3 Getting Started TCP/IP Setup By default PRN3006L IP address is 192.168.1.1 and Subnet Mask is 255.255.255.0. You are allow to change the LAN setting base your network architecture. To change the PRN3006L network setting refer to page 22 LAN Setting. - Page 13 PRN3006L is failed. The following steps is to rectify the connection issue: 1. Check physical connection between PC/Laptop and PRN3006L. Ensure the Ethernet cable is properly inserted into LAN port. At same time observe the LAN LED indicator on PRN3006L and LAN Port LED indicator on PC/Laptop (if applicable).
-
Page 14: Enter Into Web Configuration
PRN3006L is equipped with Web-based Utility configuration. Web Configuration is design for easy to setup the PRN3006L for beginner user and advanced user. Web Configuration can be open by multiple OS such as Windows, macOS and Linux. Web Configuration is not restricted to Microsoft Edge only, but user are also able to enter from Mozilla Firefox, Chrome, Opera or Apple Safari. - Page 15 PROLiNK® PRN3006L 4G LTE Wireless Router 4. If you have enter a correct Account and Password you will be redirect to Home page of PRN3006L.
-
Page 16: Enter Into Prolink Mwifi
PRN3006L can be monitor and configure through PROLiNK mWiFi mobile application. PROLiNK mWiFi is available on Android and iOS. Using PROLiNK mWiFi you are allow to monitor usage and connectivity, configure mobile network operator information, connection signal strength level, number of connected devices and SMS status. - Page 17 PROLiNK® PRN3006L 4G LTE Wireless Router 5. On the Login page enter the username and password of PRN3006L. By default PRN3006L username/password is admin/password. 6. After successfully login, you will be redirect to PROLiNK mWiFi Home page.
-
Page 18: Setup Wizard
4G LTE Wireless Router Setup Wizard PRN3006L by default is plug and play. You do not need to configure the PRN3006L. If you would like to configure the PRN3006L, you can configure using PRN3006L’s Setup Wizard. The following steps is to configure PRN3006L using Setup Wizard. - Page 19 Internet source will also available on WAN Port (LAN 2 will change to WAN Port). Leave the setting as default selection. 8. 4 Step is WiFi Settings. You can change the wireless SSID and password for PRN3006L. Default SSID and password as shown at the back of PRN3006L’s sticker.
- Page 20 4G LTE Wireless Router 9. Click Done after finish configure all the settings. A confirmation message will pop-up to reconfirm your settings before begin to reboot PRN3006L. Once confirm, PRN3006L will start to reboot. 10. After reboot finish you are redirect to Login page.
-
Page 21: Web Configuration
9. After successfully login, you will be on the Home page where all the Network status and information display. In the Web Configuration several tab is available to configure PRN3006L. The tab consists of Home, Wizard, WAN, LAN, SMS, WiFi, Security and System. -
Page 22: Home
4G LTE Wireless Router Home Home page provides the current status information about PRN3006L network. All information are continuously update with the currently status. Information consists of LAN, 4G/3G/2G Modem, System, IPV4 WAN, IPV6 WAN, Mobile Network and Dial Type. -
Page 23: Wan
Roaming mode: It is disabled by default. If disabled, data service is not allowed when roaming. If enabled, data service is allowed when roaming, but may incur significant roaming charges. • Press Disconnect or Connect to establish a connection for IPV4 and IPV6 for PRN3006L. -
Page 24: Connection Setting
WAN Mode, LAN 2 will change as a WAN Port and your WAN Access will be change to WAN Port. • LAN Mode: By default PRN3006L is on LAN Mode. LAN Mode disable WAN Access through the WAN Port. You WAN access is coming from Cellular Network of the inserted SIM Card. •... -
Page 25: 3G/2G Modem
PROLiNK® PRN3006L 4G LTE Wireless Router • APN: Access Point Name, provided by your ISP. You are recommended to keep the default value. • User: Enter Username of the APN as provided by your ISP. • Password: Enter Password of the APN as provided by your ISP. -
Page 26: Plmn
PROLiNK® PRN3006L 4G LTE Wireless Router PLMN • Mode: By default PLMN (Public Land Mobile Network) mode is configure automatically by PRN3006L. If you prefer to set manually select Manual and Consult with your ISP for the PLMN detail. -
Page 27: Lan
4G LTE Wireless Router LAN Page consist of 2 submenus. The submenus is LAN and DHCP. LAN page settings will help you to change the local network settings of PRN3006L and to configure the DHCP Server settings. • IP Address: Enter the IP address you want to use for the router. The default IP address is 192.168.1.1. - Page 28 These values will represent the last octet of the IP addresses in the pool. • Lease Time (minutes): Enter the lease time for IP address assignments. DHCP Leased Hosts is to view the information about the clients attached to the PRN3006L. • Host Name: The name of the DHCP client. •...
-
Page 29: Sms
PROLiNK® PRN3006L 4G LTE Wireless Router SMS Page consists of 6 submenus. The submenus is New Message, USSD, InBox, OutBox, DraftBox, and Settings SMS. SMS page will allow you to check, send and configure the SMS message. In this page you also able to use the USSD code to Operator carrier for request. -
Page 30: Ussd
PROLiNK® PRN3006L 4G LTE Wireless Router USSD • USSD CMD: Enter an application activation code and click Send. This will allow you to activate applications by sending an SMS message to your ISP. • USSD Read: Reply message from ISP base on application activation code. -
Page 31: Outbox
PROLiNK® PRN3006L 4G LTE Wireless Router OutBox • Number: Shows the phone number that this message was planned to be sent to. • Message: Click the message to open and read the message. • Date/Time: Shows the time when the message was sent. -
Page 32: Settings Sms
PROLiNK® PRN3006L 4G LTE Wireless Router Settings SMS • SMSC Address: Enter your SIM Card Service Center number. By default this number will automatically assign base on SIM Card. • Set up: To save the current configuration of SMSC Address. -
Page 33: Wifi
PROLiNK® PRN3006L 4G LTE Wireless Router WiFi WiFi Page consists of 4 submenus. The submenus are Basic, WPS, MAC Filter and Station List. WiFi Page help you to configure Wi-Fi setting, view client list and manage connected client. Basic •... -
Page 34: Wps
SSID from being discover by wireless client. • MAX Clients: Set the number of client limit that are allow to connect to PRN3006L. • Encryption Type: Select the desired wireless encryption mode. You can choose for WEP or WPA Personal. -
Page 35: Mac Filter
PROLiNK® PRN3006L 4G LTE Wireless Router MAC Filter • Active: The status of MAC Filter entry. Y is for activated and N is for deactivated. • Name: A simple name of MAC Filter entry. • MAC Address: The wireless station's MAC address that you want to filter. -
Page 36: Security
PROLiNK® PRN3006L 4G LTE Wireless Router Security Security Page consists of 3 submenus. The submenus is Firewall, NAT and DMZ. Security page will help you to manage network security of your network. Firewall Configure • Firewall Enable: By default Firewall is set to Disable. To enable the Firewall select Enable. -
Page 37: Nat
PROLiNK® PRN3006L 4G LTE Wireless Router IPV6 Firewall Entries The IPV6 rules section allows you to specify the kind of traffic that is allowed to pass through the network. Configure • NAT Type: Select NAT type for Symmetric, Port Restricted, Full Cone or Address Restricted. -
Page 38: Dmz
PROLiNK® PRN3006L 4G LTE Wireless Router Virtual Server PRN3006L can be configured as a virtual server so that users can access services such as Web or FTP via the public (WAN) IP address of the router. • #: To identifies the rule. -
Page 39: System
System Page consists of 9 submenus. The submenus are About, QOS, Configuration, Firmware Upgrade, Password, Date and Time, Language, UPnP and Reboot. System page provides you information and configuration for PRN3006L system setting. About About show all the information relate to device system information such as Device Name, FW Version,... -
Page 40: Qos
Configuration This section is to restore all settings back to their defaults. Any settings that have not been backed up will be lost, including any rules that you have created. To begin factory reset PRN3006L, click Reset. Firmware Upgrade Remote Server... -
Page 41: Password
PROLiNK® PRN3006L 4G LTE Wireless Router Manual Manual firmware upgrade allow you to manually upgrade the firmware through your local directory. Password • Session Timeout (Min): Duration of inactive before user begin to for logout. Value is in minute. •... -
Page 42: Language
4G LTE Wireless Router Language • Language: Select a language for the Web Configuration by click on the drop-down menu. UPnP • UPnP: Check the box to enable the UPnP function. Reboot Click Reboot button on the submenus to reboot PRN3006L. -
Page 43: Frequently Ask Question (Faq)
➢ It is NOT recommended to insert SIM Card when PRN3006L or PRN3006L with Voice is powered On as it may damage the SIM Card or the device. Please power Off the PRN3006L or PRN3006L with Voice before inserting SIM Card. - Page 44 (4) How does Call Switch Function works and how does it impact the Internet access? ➢ For PRN3006L with Voice, when there is an Incoming / Outgoing call, it may switch itself to 3G mode, Call will be maintained and Internet Access may drop for awhile and resume a few seconds later (subject to operator).
-
Page 45: Technical Specification
PROLiNK® PRN3006L 4G LTE Wireless Router 6 Technical Specification Physical Specification Physical Dimension 129x117x35mm Weight 195g Communication System (WAN) Communication System (WAN) B1/B3/B5/B7/B8/B20/B38/B40 Frequency Bands UMTS Band 1, 8 850/900/1800 MHz Bandwidth LTE Band 1.4/3/5/10/15/20 MHz, comply with 3GPP Downlink... - Page 46 PROLiNK® PRN3006L 4G LTE Wireless Router Wireless LAN Specification Wireless LAN Frequency 2.4GHz Protocol 802.11b/g/n, 20/40M Channel 1 ~ 11 Antenna Internal Antenna ( 2 x 2 ) Feature Feature LAN/WAN 2xRJ45 for 2xLANs or 1xWAN+1xLAN (Optional) RJ11 (Optional) CS Voice, VoLTE (optional)
- Page 47 PROLiNK® PRN3006L 4G LTE Wireless Router 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions IPv4/v6 VPN Passthrough Dynamic IP/Static IP/PPPoE Router Virtual Server, UPnP, DMZ DoS, SPI Firewall, IP/MAC Address Filter IP and MAC Address Binding Traffic Control (IP QoS) Local Management, Remote Management...
