Load!lO!JU[E[t]sooo
Kit No. 57362
Please read these instructions completely before proceeding with installation
Air Spring Kit Parts List
Item P/N
Description
A
58116
Air Spring
B
07129
Upper Bracket
C
03421
Lower Bracket
D
11897
Roll Plate
E
21837
Air Fitting
F
17187
3/8"-16 x 7/8" Bolt
G
18427
3/8" Lock Washer
3/8" Flat Washer, SAE
H
18444
3/8"-16 x 2" Frame Bolt
I
17171
J
17110
3/8"-16 x 5 1/2" Bolt
K
18435
3/8"-16 Nylon Lock Nut
L
17238
1/2"-13 x 1 1/2" Carriage Bolt 4
M
18485
1/2" Flat Washer, USS
N
1/2"- Nylon Lock Nut
18460
Clamp Bar
0
01426
Air Line Assembly
AA
20086
Zip tie
BB
10466
cc
Valve Cap
21230
DD
18501
M8 Flat Washer
EE
21234
Rubber Washer
Star Washer
FF
18411
GG
21233
5/16" Hex Nut
Quantity
2
2
2
4
2
8
8
28
4
8
12
4
4
4
1
6
2
2
2
2
4
Technical Support
1-800-248-0892
www.airliftcompany.com
MN-491
(022102)
ECR 9273
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LoadLIFTER5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Air Lift LoadLIFTER5000

  • Page 1 Load!lO!JU[E[t]sooo MN-491 (022102) ECR 9273 Kit No. 57362 www.airliftcompany.com Please read these instructions completely before proceeding with installation Air Spring Kit Parts List Item P/N Description Quantity 58116 Air Spring 07129 Upper Bracket 03421 Lower Bracket 11897 Roll Plate 21837 Air Fitting 17187 3/8"-16 x 7/8"...
  • Page 2: Tools Needed

    Tools Needed 1/2", 9/16" Open-end or box wrenches Hoist or floor jacks Adjustable wrench Safety stands Ratchet with 9/16", 1/2" deep well sockets Safety glasses Air compressor, or compressed air source 5/16" Drill bits (very sharp) Spray bottle with dish soap/water solution Heavy duty drill Torque wrench Hose cutter, razor blade, or sharp knife...
  • Page 3: Installing The Assembly

    2. Cut the air line assembly (AA) in two equal lengths. CAUTION: When cutting or trimming the air line, use a hose cutter (Air Lift P/N 10530), a razor blade or a sharp knife. A clean, square cut will ensure against leaks. Do not use wire cutters or scissors to cut the air line.
  • Page 4: Checking For Leaks

    You have now tested for all of the most probable leak conditions that can be easily fixed. At this point the problem is most likely a failed air spring - either a factory defect or an operating problem. Please call Air Lift at 1-800-248-0892 for assistance or a replacement air spring.
  • Page 5: Section I - Installation (To Be Completed By The Installer)

    VIII. Checklist Protect your warranty on this product and prevent unnecessary wear by ensuring the following checks have been made: Section I – Installation (To be completed by the installer): 1. Clearance Test - Inflate the air springs to 60 PSI (4BAR) and ensure there is at least 1/2 " (13mm) clearance around each sleeve from anything that might rub against them.
  • Page 6: Maintenance And Operations

    7. Should it become necessary to raise the vehicle by the frame, make sure the system is at minimum pressure (10 PSI [.7BAR] ) to reduce the tension on the suspension/brake components. Use of on–board leveling systems do not require deflation or disconnection. Thank you for purchasing Air Lift Products Mailing Address: Street Address:...
  • Page 7: Product Use Information

    No. Adding air springs will not change the weight ratings (GAWR, GCWR and/or GVWR) of a vehicle. Exceeding the GVWR is dangerous and voids the Air Lift warranty. Q. Is it necessary to keep air in the air springs at all time and how much pressure will they need? The minimum air pressure should be maintained at all times.
  • Page 8: Warranty And Returns Policy

    Warranty and Returns Policy Air Lift Company provides a limited lifetime warranty to the original purchaser of its load support products, that the products will be free from defects in workmanship and materials when used on cars and trucks as specified by Air Lift Company and under normal operating conditions, subject to the requirements and exclusions set forth in the full Limited Warranty and Return Policy that is available at www.airliftcompany.com/warranty.
