Method - KE2 Local Area Overview, Installation, And Setup Instructions

Q.5.42 June 2018
Page 2
KE2 Local AreaDashboard & Alarms
Overview, Installation, and Setup Instructions
KE2 LDA Back Label
Used to
identify
Unique for
device
each LDA
Installing the KE2 LDA: Option 1
Connecting Using the KE2 LDA as a
Permanent WiFi Service Tool
EACH DEVICE MUST HAVE A SEPARATE/
UNIQUE MODBUS ADDRESS
(See Appendix B for instructions)
© Copyright 2018 KE2 Therm Solutions, Inc., Washington, Missouri 63090
Serial #:
16197-251 Power: 5V-1A
MAC: EF:95:6E:40:87:F3
WIFI ESSID: KE2LDA-4087F3
WIFI PW: 3YzliZmQyZTI4
MGMT LOGIN: ke2admin
MGMT PW: 3YzliZmQyZTI4
http:ke2lda or IP: 192.168.50.1
Plug power cable into the KE2 LDA
and the other end into an electrical outlet.
The unit will power on automatically.
thermsolutions thermsolutions
KE2 Temp KE2 Temp
. .
Hold for manual defrost Hold for manual defrost
Serial-Modbus Controllers:
KE2 Temp, KE2 Low Temp, KE2 Adaptive Control
KE2 LDA Side View
QR Code
Links to
Setup Page
• KE2 Evaporator E ciency, KE2 Evap for Rack E ciency,
or KE2 Controlled Environment
• DHCP Enabled or set address from
192.168.50.2 to 192.168.50.99
• Check IP address from front panel if DHCP
• Factory assigned 10.10.x.x addresses are now visible when
connected to the LAN port. However, 10.10.x.x controllers can
thermsolutions TM
KE2 EvaporatorEfficiency
only be managed by PC, phone, or tablet when wirelessly
.
connected to the KE2 LDA.
ENTER
BACK
Connect Customer Network
Power
LAN
WAN
B
A
USB Reset
OFF ON
WiFi Switch
thermsolutions TM
KE2 EvaporatorEfficiency
.
ENTER
BACK
Ethernet Controllers:
KE2 Evaporator E ciency,
KE2 Evap for Rack E ciency,
WiFi to PC/Laptop,
Tablet, Phone KE2 Controlled Environment
NOTE: DHCP or Static IP in
Customer Network
ABC Contracting
(888)555-3358 Evaporator Fan
Off All Clear
System Mode
Cool
Superheat Suct Pressure Suct Temp
0.0 F 96.2 F 87.7 F
Connect wirelessly
to the LDA Network
.
thermsolutions TM
KE2 EvaporatorEfficiency
.
ENTER
BACK
