FLUID NOZZLE / AIR CAP SELECTION CHARTS
LYNX SERIES 100 - Pressure / Siphon Feed Guns
L100H HVLP SPRAY GUN
MATERIAL TYPE
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
L100C CONVENTIONAL SPRAY GUN
MATERIAL TYPE
Very Thin
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
FLUID ORIFICE x
AIR CAP
0.5, 0.8 mm x 1090
0.5, 0.8 mm x 1092
1.0, 1.2 mm x 1092
1.0, 1.2 mm x 1093
1.3, 1.4, 1.5 mm x 1093
1.3, 1.4, 1.5 mm x 1095
1.3, 1.4, 1.5 mm x 1097
1.6, 1.7 mm x 1095
1.6, 1.7 mm x 1097
1.6, 1.7 mm x 1195
1.6, 1.7 mm x 1197
FLUID ORIFICE x
AIR CAP
0.6, 0.7 mm x 2163
0.6, 0.7 mm x 2166
0.6, 0.7 mm x 2266
0.6, 0.7, 1.0 mm x 2163
0.6, 0.7, 1.0 mm x 2366
0.6, 0.7, 1.0 mm x 2466
1.2, 1.3, 1.5, 1.8 mm x 2263
1.2, 1.3, 1.5, 1.8 mm x 2266
1.2, 1.3, 1.5, 1.8 mm x 2266-3
1.2, 1.3, 1.5, 1.8 mm x 2466
1.5, 1.8mm x 2466
2.2 mm x 2167
2.2 mm x 2267
2.8 mm x 2168
MAXIMUM
PRESS. / SIPHON
PATTERN WIDTH
10
11
11
12
12
12
13
12
13
13
14
MAXIMUM
PRESS. / SIPHON
PATTERN WIDTH
8
9
12
8
14
13
14
10
15
13
13
12
15
12
P
P
P
P
P
P
P
P
P
P
P
P
S
S
P
S
S
P
S
S
S
S
P
P
P
