C.A. Technologies Lynx L200C Quick Start Manual

DISTRIBUTED BY COATING EQUIPMENT TECHNOLOGY, INC
PHONE: 586-210-0555
WEB: www.cetinc.com
CONVENTIONAL AIR CAP AND FLUID NOZZLE CHART
MODEL
AIR CAPS
NO.
22-2030
22-2058
22-2080
22-2062**
22-2064**
L200C
22-2704
22-2765
22-2777
22-2797
22-2880
22-2900
Actual fluid nozzle and air cap combinations are determined by application (see application chart page 4)
*Gun inlet pressures may vary as required by application
**Air caps available with teflon coating (22-2062T & 22-2064T)
*SUGGESTED
Press /
GUN INLET
Siphon CONTROL
PRESS.
siphon 50
p & s 40
siphon 60
pressure 80
pressure 80
pressure 70
pressure 80
pressure 70
pressure 70
siphon 60
siphon 45
PRESSURE/SIPHON FEED SPRAY GUN
FAN AIR CAP
SCFM
RING
12
6
included
14
19
22
60-1500
21
22
22-1001
23
21
15 included
12 22-1001
L L L L L ynx 200C ynx 200C ynx 200C ynx 200C
ynx 200C
PRODUCT INFORMATION
AVAILABLE FLUID
NOZZLES
32-0611 1.1mm (.042")
32-0614 1.4mm (.055")
32-0618 1.8mm (.070")
32-0618V 1.8mm (.070")
32-0818 1.8mm (.070")
32-0622 2.2mm (.086")
32-0622V 2.2mm (.086")
32-0628 2.8mm (.110")
32-0628V 2.8mm (.110")
NEEDLES /
marking on needle
40-1211 (211)
40-1214 (214)
40-1218 (218)
40-5301
40-1222 (222)
40-5301
40-1228 (228)
40-5301
