Quick start proceDure
troubleshooting
If the green LED does not illuminate, follow the instruc-
tions below:
1. Verify that you are able to communicate with the
DC1795A. The bottom status line in ClockWizard should
read "LTC6950" and "Comm Enabled."
+
2. Verify that V
VCXO turrets have the correct voltages on them (see
the Typical DC1795A Requirements and Characteristics
table).
Dc1795a reconfiguration
The DC1795A allows the use of a variety of references,
VCOs and active or passive loop filters. The following
covers the hardware reconfiguration of the DC1795A.
Refer to ClockWizard and the LTC6950 data sheet to bet-
ter understand how to change programmed parameters
on the DC1795A.
ltC6950 Clkset Files
The ClockWizard provides three different clkset files for
evaluation purposes. These files were made for the default
bill of materials. If board modifications are made, these
files or the loop filter may need to be modified for the
LTC6950 to lock correctly.
1. LTC6950_PECL0_250MHz.clkset: Produces a 250MHz
output on PECL0. All other outputs are powered down.
2. LTC6950_Figure16_250MHZ.clkset: Matches Figure
16 of the LTC6950 data sheet. To sync outputs, refer
to the EZSync Function section.
3. LTC6950_ALL_CHAN_250MHz.clkset: Produces a
250MHz output on all five outputs. To sync outputs,
refer to the EZSync Function section.
