Selected Measurement Concepts

Microsense probes measure displacement. Measurements which may be derived using the Model 5300
gaging system are described briefly in the pages which follow.

Displacement

"Displacement" is the distance change between the probe and a target surface.
Surface variations can be examined by measuring displacement values over the entire surface of a moving
object.
