Onicon SeaMetrics EX90 Quick Start Manual

Check Components Check Components
Meter with Indicator
and hinged cover
Saddle Gasket
Recommended Tools Recommended Tools
Recommended:
• 3/32" or 2.5mm (small) flat head screw driver
• Crescent Wrench
• 5/32" Hex Key
Warnings Warnings
Refer to instruction manual for further details.
• Confirm that U-clip retainer is installed and never remove the
U-clip retainer when pipe is under pressure—may result in
serious injury.
• Saddle bolts must be tightened evenly. Do not over tighten.
• Install security seal during installation if regulations require.
253.872.0284
EX90 Propeller Replacement
Saddle Assembly
(Packaged Separately)
Cable Gland
Page 1 of 4
Quick Start Guide
Display Security Seal
Optional Optional
Power/Output Cable
Optional:
• Channel locks
• 6" Strap Wrench
• Improper sealing of cables or cable glands will void warranty.
• Ensure proper grounding when required.
• Programming pipe ID, pipe insertion hole size and straight pipe
configuration is required for the meter to read.
U-clip Retainer
seametrics.com
