Acnodes KD 9200 Specifications

» Specifications
Material:
Heavy-duty steel
Keyboard and mouse:
PS/2 101 keys keyboard
Standard PS/2 optical mouse
LCD Panel:
Size: 20.1"
Resolution: 1600 x 1200
Brightness (cd/m^): 250nit
Contrast Ratio: 700:1
Pixels Pitch: 0.255mm x 0.255mm
Responsible Time: 25msec
Active Area: 408.0 (H) x 306.0 (V)
Scan Frequencies:
Horizontal 31.47KHz to 68KHz
Vertical 80Hz to 68 Hz
Colors: 16.7M colors
Power Consumption: 45W (type)
Connectors:
1 x D-Sub 15 pin (female) for VGA
1 x P/S 2 for Keyboard
1 x P/S 2 for Mouse
1 x Audio out for Built-in speaker
Cables:
Built-in 6' cable for VGA, Keyboard, touch pad and Audio
LCD Protection:
Tempered glass in front of the LCD panel
Security Lock:
Drawer lock for system security
Drawer Design:
High load-rating slide rail with angle bracket extension up to
30.00" depth
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KD 9200
20" 1600x1200 LCD monitor
PS/2 keyboard/optical mouse
2 U rackmount drawer
» Features
» 2 U rackmount compact design, only 19.4" depth
» 20" 1600x1200 TFT LCD display
» OSD (On Screen Display) function
» 101-keys keyboard with standard optical mouse
» Built-in stereo speakers
» External 110/220VAC power adapter
Speaker:
Built-in Stereo speaker
Power Adapter:
Industrial level Auto-switching power supply for 85V~264V AC
input
Color:
Black
Operation Temperature:
0°C to 50°C
Weight:
40lb
Dimension:
19"(W) x 19.4"(D) x 3.5"(H
» Options
» Ordering Guide
KD 9200:
2U 20" 1600x1200 rackmount monitor keyboard drawer
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
