  • Page 1 KDM-3170/8/16 Dual Rail LCD Console User’s Manual Rev 1.0...

  • Page 2: Packing List

    The complete KDM 3170 package consist of: One 1U 19” rack mount console Single Bracket x 2 Flat Screw x 4 (For short single bracket) Key x 1 One 1.8M signal cable One power cord One user manual CD One quick installation guide The complete KDM 3198/16 packages consist of: One 1U 19”...

  • Page 3: Safety Instructions

    The equipment has been exposed to moisture. The equipment has not worked well or you can not get it work according to User’s Manual. The equipment has dropped and damaged. If the equipment has obvious signs or breakage. KDM 3170/8/16 User manual afety Instructions...

  • Page 4: Table Of Contents

    Index of Contents ... 4 1. General Information ... 5 1.1 Overview ... 5 1.2 Product Specification ... 6 1.2.1 KDM 3170 Specification...6 1.2.1 KDM 3178 Specification...7 1.2.1 KDM 31716 Specification...8 2. Rack Mount Installation ... 9 3. OSD Menu ... 11 4.

  • Page 5: General Information

    KDM 3170/8/16 User manual 1. General Information 1.1 Overview The KVM console is an ideal solution for network administration with multiple servers / platforms. The 19-inch large size TFT LCD color display and ultra-low-profile compact industrial keyboard / touchpad provide the user-friendliest and most reliable environment for network administrators. All these functions are integrated in a 19-inch 1U space with rugged construction design to achieve ultra space saving and high reliability for high quality industrial network applications.

  • Page 6: Product Specification

    1.2 Product Specification 1.2.1 KDM 3170 Specification Model name Number of ports Dimension Net Weight Display Size Panel Type Resolution Capabilities Viewing Angle (CR>10) Contrast Ratio Brightness Back Light Supported Colors Folding View Angle Operating System Multi Platform System Cables...

  • Page 7: Kdm 3178 Specification

    Humidity Chassis Construction Keyboard Language Certification KDM 3170/8/16 User manual KDM 3178 631.3 x 443.5 x 44 mm / 23.2 x 17.5 x 1.7 inches 13.5 Kg / 30.0 lbs 17 inches Active Matrix TFT LCD Maximum Resolution up to 1280 x 1024 (SXGA) Supports 0.098 mm x 0.294 mm...

  • Page 8: Kdm 31716 Specification

    Humidity Chassis Construction Keyboard Language Certification KDM 3170/8/16 User manual KDM 31716 631.3 x 443.5 x 44 mm / 23.2 x 17.5 x 1.7 inches 13.5 Kg / 30.0 lbs 17 inches Active Matrix TFT LCD Maximum Resolution up to 1280 x 1024 (SXGA) Supports 0.098 mm x 0.294 mm...

  • Page 9: Rack Mount Installation

    KDM 3170/8/16 User manual 2. Rack mount Installation 1. Find the property position to screw these two extension brackets with the ears and both side onto the server rack mount first. 2. Lift & push the KDM 317X inside the rack mount, and screw between bracket and KDM317X with 4 screws.
  • Page 10 KDM 3170/8/16 User manual Maximum Extension Length Up To 120∘ 328 mm The view of single & double tray situation...

  • Page 11: Osd Menu

    KDM 3170/8/16 User manual 3. OSD Menu...
  • Page 12 KDM 3170/8/16 User manual Auto Adjustment Bright & Contrast...

  • Page 13: Image Adjustment

    KDM 3170/8/16 User manual Image Adjustment...

  • Page 14: Color Adjustment

    KDM 3170/8/16 User manual Color Adjustment...

  • Page 15: Language Selection

    KDM 3170/8/16 User manual Language Selection Reset...
  • Page 16 KDM 3170/8/16 User manual...
  • Page 17 KDM 3170/8/16 User manual...

  • Page 18: Osd Menu For Kvm Operation

    / : SELECT PORT To use “ PgUp “ key or “ PgDn” key for selecting previous or next Bank no. (or Box No.) PgDn/PgUp: BANK SELECT KDM 3170/8/16 User manual a. The 1 b. The 2 system name list. You will ☼SYSTEM 02...
  • Page 19 Enter. The maximum password is eight digits. After you key in the password already and press the Enter key, there is another window for confirming your typed password. KDM 3170/8/16 User manual ENTER :COMPLETE INSERT :EDIT CHANGE PASSWORD...
  • Page 20 LEDs on the front panel will be flashed during the refresh process. When the OSD value back to default setting, the seven segment LEDs on the front panel will stop flashing KDM 3170/8/16 User manual █ ENTER : COMPLETE █...

  • Page 21: Kvm Switch

    KDM 3170/8/16 User manual 5. KVM Switch 5.1 KVM Connector Diagrams PC Port Special Cable: HDB15 pin male to one HDDB 15 pin male and Mini Din 6 pin special cables 5.2 KVM Port Connection Diagrams Before installation, please make sure all of peripherals and computers have been turned off.

  • Page 22: 8/16 Port Kvm Usage

    KDM 3170/8/16 User manual Step 3 Connect the first computer’s keyboard cable to the KVM Switch. Using another PS/2 cable connect one end to PS/2 keyboard port on the computer, and the other end to the PC1 keyboard port on the back of KDM 317X. If your computer has an AT type keyboard port, you will need a PS/2 to AT keyboard adapter.

  • Page 23: 8/16 Port Kvm Hot Plug Commands

    Lock Scroll Scroll Lock Lock To get out of Auto Scan Mode, Press any key or SPACE bar. KDM 3170/8/16 User manual The “SCROLL LOCK” key must be ↑ Previous Channel ↓ Next Channel (Note: You also could press “up arrow key” or “down arrow key”...
  • Page 24 Bank no. and Port no. selection must be made using the numeric keys on the keyboard. Numeric keys on the keypad are not available as a hot key command. KDM 3170/8/16 User manual OSD default value (Note: Not including password)

  • Page 25: Daisy Chain Cobbection Diagram

    D. Before chaining the slave bank up to six banks, you need a VGA extender (Model No. VGA-100, Max. 100 feet ) between the fifth bank and the sixth bank to enhance the VGA signal. Maximum 8 Levels KDM 3170/8/16 User manual Bank:1 Bank:2 Bank:3...

  • Page 26: 8/16 Port Kvm Cable Hot Plug

    Plug ” function. If you apply “Hot Plug” to this kind of O.S., it will cause unpredictable behavior or shut down the PC. Before attempting to use “ Hot Plug ” , please make sure your O.S. and software driver supports the “Hot Plug” function. KDM 3170/8/16 User manual...

  • Page 27: Trouble Shooting

    5 sec. or more. Normally, the VGA monitor change one resolution mode to another will take a few seconds. 7. If forgetting the “ password ” you typed, please contact your supplier to rest the password. KDM 3170/8/16 User manual...

  • Page 28: Kvm Accessory

    KVM switch Devices (PC, iMAC or SUN platforms) Support standard PS/2 Mouse and • Microsoft Intellimouse Eas install • Bus power, External power Adapter Not • Required Complies to USB 1.0 and 1.1 Specification • Support UHCI and OHCI USB Interfaces • KDM 3170/8/16 User manual...
