Acnodes KD 9151N Specifications

» Specifications
Material:
Heavy-duty steel
LCD Panel:
Size: 15"
Max. Resolution: 1024x768
Brightness 330 cd/m2
Contrast Ratio 250:1
Frequency Horizontal: 31.5 to 80KHz.
Vertical: 56 to 75Hz.
Response Time 25 ms typical
Viewing Angle:
Horizontal: -80/ +80 degrees
Vertical: -80 / +80 degrees
Input Signal Video: Analog RGB
Sync: H/V Separate (TTL Brightness (cd/m^): 250nit)
Colors 16M colors
Video Connector Signal: 15-pin mini D-sub, detachable
Plug & Play: DDC1 and DDC2B
On-Screen-Controls:
Brightness, Contrast, Position (Vertical & Horizontal)
Auto Adjust, OSD Horizontal & Vertical, position, Load and Save
values.
Keyboard:
Compatibility: IBM AT, PS/2, DOSV
Key layout: 88 keys
Switch life: 5 million life cycles
» Ordering Guide
KD 9151N:
1U 15" 10246 x 768 rackmount monitor keyboard drawer ,
optical mouse
20947 Currier Road Suite #H
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KD 9151N
15" 1024 x 768 LCD monitor
Built-in keyboard / Optical mouse
1U rack mount drawer
» Features
» 1U rackmount compact design, only 25" depth
» 15" 1024 x 768 TFT LCD display
» OSD (On Screen Display) function
» 88-eys keyboard
» standard optical mouse
» 110/220VAC 50W power supply
Mouse:
Microsoft IntelliMouse optical PS/2 or USB mouse
Connectors
1 x D-Sub 15 pin (female) for VGA
1 x P/S 2 for Keyboard
1 x P/S 2 or USB for optical mouse
Drawer Design:
High load-rating slide rail with angle bracket extension up to 35"
depth
Power Adapter:
Industrial level Auto-switching 60W power supply for 85V~264V
AC input
Color:
Black
Environmental:
Environment Temperature Operating: 0 to 50 degrees C
Storage: -20 to 60 degrees C
Humidity Operating: 10% to 85% non-condensing
Gross Weight:
23lb
Dimension:
19"(W) x 25"(D) x 1.75"(H)
» Options
