Instrument Overview - Flytec 3040 Operation Manual

1.

Instrument overview

6
5
4
1 On/Off switch (ON2-OFF-ON1)
2 Keypad
3 Lanyard
4 TT34 Receiver On/Off switch
5 Wind speed sensor jack
6 Envelope / Ambient temperature / Real-time clock / Stopwatch display
7 Altimeter feet / Altimeter meters / QNH display
8 Graphic variometer display
9 Battery compartment (2 x 9 Volt battery)
10 Digital variometer / Wind speed display (with optional sensor)
