Acnodes RP 1150 Specifications

» Specifications
Material:
Heavy-duty steel
LCD Panel:
Size: 15"
Resolution: 1024 x 768
Brightness: 450nit
Contrast Ratio: 300:1
Viewing Angle:
140 ° (H) x 120 ° (V) (Typ.)
Response Time:Tr=5ms, Tf=20ms (Typ.)
Pixel pitch: 0.297(H) x 0.297(W) mm
Colors: 16M colors
Back Light: 4 CCFTs
MTBF: 20,000 hours
Optional for S-video and DVI ports
Touch screen (optional):
Resistive-type, RS-232 / USB port
Thickness : 2.2mm
Light transmission: 87%
Durability: 35 million
On Screen Control:
Auto-Adjustment for
contrast, balance, H-position,
V-position, phase, brightness
Front Panel Controls
Power on/off switch
OSD (on screen control)
Security Lock:
Drawer lock for system security
Connectors:
1 x D-Sub 15 pin (female) for VGA
Cable:
1 x 6' 15-pin VGA cable
20947 Currier Road Suite #H
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
RP 1150
15" 1024 x 768 LCD monitor
1U rack mount drawer
» Features
» 1U drawer type design, only 1.75" height
» 15" 1024 x 768 TFT LCD display
» OSD (On Screen Display) function
» Angle bracket extension up to 29.13" depth
» Drawer lock for system security
» 110/220VAC power supply
Power supply:
110/220VAC power supply
Optional for -48VDC input
Color:
Black
Operation Temperature:
0° to 55° C (32° to 131° F)
Safty:
FCC , CE
Gross Weight:
34lb
Dimension:
19"(W) x 21.7"(D) x 1.75"(H)
» Options
CB-10-VGA: 10' VGA cable
CB-15-VGA: 15' VGA cable
CB-20-VGA: 20' VGA cable
CB-25-VGA: 25' VGA cable
» Ordering Guide
RP 1150: 1U 15" 1024 x 768 rackmount monitor drawer
RP 1150TR: 1U 15" 1024 x 768 rackmount monitor drawer with
touch screen (RS-232)
RP 1150TU: 1U 15" 1024 x 768 rackmount monitor drawer with
touch screen (USB)
