Acnodes RP 1200 Specifications

» Specifications
Material:
Heavy-duty steel
LCD Panel:
Size: 20"
Resolution: 1600 x 1200
Brightness: 280nit
Contrast Ratio: 700:1
Viewing Angle: 178° (H) x 178°(V) (Typ.)
Pixel pitch: 0.255(H) x 0.255(W) mm
Response Time: Tr=6ms, Tf=10ms (Typ.)
Back Light: 4 CCFTs
Colors: 16M colors
MTBF: 50,000 hours
Optional for S-video and composite video-input
Optional For touch screen (RS-232/USB)
Touch screen (optional):
Resistive-type, RS-232 / USB port
Thickness : 2.2mm
Light transmission: 87%
Durability: 35 million
On Screen Control:
Auto-Adjustment for
contrast, balance, H-position,
V-position, phase, brightness
Front Panel Controls
Power on/off switch
OSD (on screen control)
Security Lock:
Drawer lock for system security
Connectors:
1 x D-Sub 15 pin (female) for VGA
Cable:
1 x 6' 15-pin VGA cable
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
RP 1200
20" 1600 x 1200 LCD monitor
2U rack mount drawer
» Features
» 2U drawer type design, only 1.75" height
» 20" 1600 x 1200 TFT LCD display
» OSD (On Screen Display) function
» Angle bracket extension up to 29.13" depth
» Drawer lock for system security
» 110/220VAC power supply
Power supply:
110/220VAC power supply
Optional for -48VDC input
Color:
Black
Operation Temperature:
0° to 55° C (32° to 131° F)
Safty:
FCC , CE
Gross Weight:
34lb
Dimension:
19"(W) x 23.6"(D) x 3.5"(H)
» Options
CB-10-VGA: 10' VGA cable
CB-15-VGA: 15' VGA cable
CB-20-VGA: 20' VGA cable
CB-25-VGA: 25' VGA cable
» Ordering Guide
RP 1200: 2U 20" 1600 x 1200 rackmount monitor drawer
RP 1200V: 2U 20" 1600 x 1200 rackmount monitor drawer with
S-video and composite video input
RP 1200TR: 2U 20" 1600 x 1200 rackmount monitor drawer with
touch screen (RS-232)
RP 1200TU: 2U 20" 1600 x 1200 rackmount monitor drawer with
touch screen (USB)
