Acnodes RP 1152 Specifications

» Specifications
Material:
Heavy-duty steel
LCD Panel:
Size: 15"
Resolution: 1024 x 768
Brightness: 450nit
Contrast Ratio: 300:1
Viewing Angle:
140 ° (H) x 120 ° (V) (Typ.)
Response Time:Tr=5ms, Tf=20ms (Typ.)
Pixel pitch: 0.297(H) x 0.297(W) mm
Colors: 16M colors
Back Light: 4 CCFTs
MTBF: 20,000 hours
Optional for BNC, S-video and DVI ports
Touch screen (optional):
Resistive-type, RS-232 / USB port
Thickness : 2.2mm
Light transmission: 87%
Durability: 35 million
On Screen Control:
Auto-Adjustment for
contrast, balance, H-position,
V-position, phase, brightness
Front Panel Controls
Power on/off switch
OSD (on screen control)
Security Lock:
Drawer lock for system security
Connectors:
1 x D-Sub 15 pin (female) for VGA
Cable:
1 x 6' 15-pin VGA cable
20947 Currier Road Suite #H
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
RP 1152
15" 1024 x 768 LCD monitor
1U rack mount drawer
» Features
» 1U drawer type design, only 17.3" depth
» 15" 1024 x 768 TFT LCD display
» OSD (On Screen Display) function
» Angle bracket extension up to 26" depth
» Drawer lock for system security
» 110/220VAC power supply
Power supply:
110/220VAC power supply
Optional for -48VDC input
Color:
Black
Operation Temperature:
0° to 55° C (32° to 131° F)
Safty:
FCC , CE
Gross Weight:
34lb
Dimension:
19"(W) x 17.3"(D) x 1.75"(H)
» Options
CB-10-VGA: 10' VGA cable
CB-15-VGA: 15' VGA cable
CB-20-VGA: 20' VGA cable
CB-25-VGA: 25' VGA cable
» Ordering Guide
RP 1152: 1U 15" 1024 x 768 rackmount monitor drawer
RP 1152TR: 1U 15" 1024 x 768 rackmount monitor drawer
with touch screen (RS-232)
RP 1152TU: 1U 15" 1024 x 768
with touch screen (USB)
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
rackmount monitor drawer
