Fenix LD03 Manual

High-intensity penlight

Download this manual

Fenix LD03 is a high-intensity penlight, designed for engineers, doctors, etc. Its compact size

makes it workable in the extremely narrow areas. The pushbutton in the tail cap, plus with the clip,

makes it easy to operate and convenient to carry. Three brightness levels can satisfy your

illuminating needs in various conditions. LD03 can also be the best choice as a gift with its elegant

appearance.

Technical Parameters

ANSI/FSC

OUTPUT

RUNTIME

DISTANCE

INTENSITY

IMPACT

RESISTANT

WATERPROOF

EXTRA

FUNCTION

ACCESSORY

Cree XP-E LED (R2) with a lifespan of 50,000 hours

Uses one 1.5V AAA (Ni-MH, Alkaline) batteries

118mm (Length) x 12.8mm (Diameter)

27.6-gram weight (excluding batteries)

Digitally regulated output - maintains constant brightness

LD03 Flashlight

Mid

LUMENS

2h 26min

IPX-8, underwater 2m

Low

LUMENS

17h

45m

514cd

1.5m

spare o-ring

Turbo

LUMENS

51min

Page 1 The pushbutton in the tail cap, plus with the clip, makes it easy to operate and convenient to carry. Three brightness levels can satisfy your illuminating needs in various conditions. LD03 can also be the best choice as a gift with its elegant appearance.
Page 2 Solution: Clean the contact points with an alcohol soaked cotton swab. If the above methods don't work, please contact the distributors and refer to the warranty policy. Notice: The routine cleaning video can be watched and downloaded through Fenix official website, please log onto the service channel->'maintenance for light'.
Page 3 What's more, you could take part in the lottery of questionnaire at the same time. Warning The LD03 is a high-intensity lighting device and capable of causing eye damage; avoid shining the light directly into the eyes. Avoid the use of 10440 or 10450 rechargeable Li-ion batteries or damage will be caused to the light circuit.
