Summary of Contents for Ezviz CS-CV228
- Page 1 www.ezvizlife.com...
- Page 3 COPYRIGHT ©2018 Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries. ALL RIGHTS RESERVED. About this Manual The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
-
Page 4: Regulatory Information
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. -
Page 5: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Hereby, Hangzhou Hikvision Digital Technology Co., Ltd. declares that the radio equipment type [CS-CV228, CS-CV226, CS-CV220, CS-CV320, CS-CV326, CS-CV328, CS-CV420, CS-CV426, CS- CV428] is in compliance with Directive 2014/53/EU. The full text of the EC DECLARATION OF CONFORMITY is available at the following web link: http://www.ezvizlife.com/declaration-of-conformity. -
Page 6: Box Content
Box Content Camera (x1) Power Adapter (x1) Drill Template (x1) Screw Kit (x1) Waterproof Kit (x1) Quick Start Guide (x1) Base (x1) Basics Lens IR Light LED Indicator (Inside) - Page 7 • Slowly Flashing Red: Wi-Fi connection has failed. • Fastly Flashing Red: Device exception (e.g. MicroSD card error). • Solid Blue: Video is being viewed or played back in EZVIZ App. • Flastly Flashing Blue: Device is ready for the Wi-Fi connection.
- Page 8 Operations Step 1 Power-on Option 1 Power on the device by connecting to the power outlet by a power cable. Option 2 Power on the device by PoE switch (Purchased Separately). Option 1 Power Outlet Power Cable Option 2 Router Network Cable PoE Switch...
- Page 9 Create an user account - Connect your mobile phone to Wi-Fi. - Download and install the EZVIZ app by searching “EZVIZ” in App Store or Google Play - Launch the app and register for an EZVIZ user account following the start-up wizard.
-
Page 10: Mounting (Optional)
Step 3 Mounting (Optional) The camera can be mounted on the wall or ceiling. Here we take wall mounting as an example. Make sure the wall/ceiling is strong enough to withstand three times the weight of the camera and the mounting. Install the mounting template Place drill template onto the surface you have chosen to mount the camera. - Page 11 Install the Camera Mount the camera to the mounting plate. Turn it clockwise until it is fixed. For side wiring Rotate camera as shown in the figure. For top wiring Rotate camera as shown in the figure.
- Page 12 Installing the waterproof kit (Optional) If the camera is installed outdoors or in the humid environment, please use the waterproof kit. Cut off one side of the network cable (A). Put the A side through the gasket and the encap. Connect a new network plug with the cable (A).
- Page 13 Adjusting the Surveillance Angle Turn the camera as shown in the figure. Loosen the rotary knob. Adjust angle Tighten the rotary knob. For detailed information, please refer to www.ezvizlife.com.
