Icom IC-208H Adjustment Procedure page 11

SOFTWARE ADJUSTMENT-Continued
ADJUSTMENT
SQUELCH 1 • Operating frequency
LEVEL • Connect an SSG to the antenna connector and set as
(Wide) Level
[SqW] Modulation
Deviation
• Receiving
2 • Operating frequency
• Receiving
3 • Operating frequency
• Set an SSG as:
Level
• Receiving
4 • Operating frequency
• Set an SSG as:
Level
• Receiving
(Narrow) 5 • Operating frequency
[SqN] • Connect an SSG to the antenna connector and set as
Level
Modulation
Deviation
• Receiving
6 • Operating frequency
• Receiving
7 • Operating frequency
• Set an SSG as:
Level
• Receiving
8 • Operating frequency
• Set an SSG as:
Level
• Receiving
TEMP. 1 • Operating frequency
• Receiving
CORRECTION
<High power>
(VHF –10˚C)
[HP–]
(VHF +60˚C) 2 • Operating frequency
• Receiving
[HP–]
<Mid. power> 3 • Operating frequency
(VHF –10˚C) • Receiving
[MP–]
(VHF +60˚C) 4 • Operating frequency
• Receiving
[MP–]
<Low power> 5 • Operating frequency
• Receiving
(VHF –10˚C)
[LP–]
6 • Operating frequency
(VHF +60˚C)
[LP–] • Receiving
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
: 146.1 MHz
: 0.079 µV* (–129 dBm)
: 1 kHz
: ± 3.5 kHz
: 445.1 MHz
: 435.1 MHz
: 0.1 µV* (–127 dBm)
: 810.1 MHz
: 0.25 µV* (–119 dBm)
: 146.1 MHz
: 0.071 µV* (–130 dBm)
: 1 kHz
: ± 3.5 kHz
: 445.1 MHz
: 435.1 MHz
: 0.1 µV* (–127 dBm)
: 810.1 MHz
: 0.25 µV* (–119 dBm)
: 146.0 MHz
: 146.0 MHz
: 146.0 MHz
: 146.0 MHz
: 146.0 MHz
: 146.0 MHz
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
•Turn the [DIAL] to set to "F9" on the display.
• Push the [BAND] key.
