Icom IC-208H Adjustment Procedure page 10

SOFTWARE ADJUSTMENT-Continued
ADJUSTMENT
TRACKING 9 • Operating frequency
(Middle2 • Connect an SSG to the antenna connector and set as
band) Level
[Tr] Modulation
Deviation
• Receiving
10 • Operating frequency
• Receiving
11 • Operating frequency
• Receiving
12 • Operating frequency
• Receiving
(High band) 13 • Operating frequency
[Tr] • Connect an SSG to the antenna connector and set as
Level
Modulation
Deviation
• Receiving
14 • Operating frequency
• Receiving
15 • Operating frequency
• Receiving
1 • Operating frequency
S-METER
[SL] • Connect an SSG to the antenna connector and set as
Level
Modulation
Deviation
• Receiving
2 • Operating frequency
• Receiving
3 • Operating frequency
• Receiving
4 • Operating frequency
• Set an SSG as
Level
Modulation
Deviation
• Receiving
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
: 400.1 MHz
: 1 µV* (–107 dBm)
: 1 kHz
: ± 3.5 kHz
: 429.9 MHz
: 480.1 MHz
: 549.9 MHz
: 810.1 MHz
: 1 µV* (–107 dBm)
: 1 kHz
: ± 3.5 kHz
: 905.1 MHz
: 999.9 MHz
: 146.1 MHz
: 1 µV* (–107 dBm)
: 1 kHz
: ± 3.5 kHz
: 445.1 MHz
: 435.9 MHz
: 810.1 MHz
: 5.6 µV* (–92 dBm)
: 1 kHz
: ± 3.5 kHz
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
• Push the [BAND] key.
9
OPERATION
