Examples
VX4101A MultiPaq Instrument User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Query
TRIGger([:SEQuence1]|:
STARt)[:LAYer]:SOURce:
CATalog:DELayable?
TRIGger([:SEQuence1]|:
STARt)[:LAYer]:SOURce:
CATalog:FIXed?
TRIGger ([:SEQuence1] |:STARt)[:LAYer]:DELay
Command
INST:SEL DAC
TRIG:SOUR TTLT0
TRIG:DEL 1E-3
INIT CONT ON
TRIGger ([:SEQuence1] |:STARt)[:LAYer]:ECOunt
Command
INS:SEL DAC
TRIG:SOUR TTLT0
TRIG:ECO 100
INIT CONT ON
TRIGger ([:SEQuence1] |:STARt)[:LAYer]:IMMediate
Command
TRIG:SOUR:CAT?
INST:SEL DAC
TRIG:SOUR TTLT0
INIT
TRIG:IMM
SCPI Commands for the Digital to Analog Converter
Response
Lists all delayable trigger sources available for use with the
TRIG:SOUR command.
BUS, EXTERNAL, TTLTRG0, TTLTRG1, TTLTRG2, TTLTRG3,
TTLTRG4, TTLTRG5, TTLTRG6, TTLTRG7, COMMAND0,
COMMAND1, COMMAND2, COMMAND3, COMMAND4,
SUREPATH, DMM, COUNTER, CTR_EXTARM, DAC, DIGI,
DIGO
Lists all fixed trigger sources available for use with the
TRIG:SOUR command.
HOLD, IMMEDIATE, TIMER, HANDSHAKE
Response
TTLT0 is delayed by 1 ms.
Response
The DAC is triggered once per 100 TTLT0 triggers
Response
IMMEDIATE, BUS, TTLTRG0, TTLTRG1, TTLTRG2,
TTLTRG3, TTLTRG4, TTLTRG5, TTLTRG6, TTLTRG7,
COMMAND0, COMMAND1, COMMAND2, COMMAND3,
COMMAND4, TIMER, SUREPATH, DMM, COUNTER,
CTR_EXTARM, DAC, DIGI, DIGO, HANDSHAKE
Selects TTLT0 trigger source
Triggers the instrument using software command
3–191
