KB2LJJ Radio Mods Database
Icom IC-706MK2 cw keyer
Author: colin f5vhz - f5vhz@yahoo.co.uk.
This mod is for the mic of a IC-706MK2. This allows better use of cw by installing a paddle in the mic.
Wire the contacts of a dissassembled relay with an isolated paddle (important) to the up down contacts and remove the old buttons
from the small board and glue them in to the top of the mic to fill the holes
enjoy colin f5vhz
http://www.kb2ljj.com/data/icom/ic-706-MKII.htm (23 di 30)23/08/2009 23.05.07
