from under IC-31, and stops. It should be the sixth trace up from
the top of the Chip.
6. Using a Xacto knife, (or something similar) Cut the trace the bend
halfway between IC-31 and the solder point.
7. Make a jumper wire, and jump the connection, from Pin 11 of IC-32
to the newly isolated trace.
8. Reassemble the radio.
Transmit from 200 Hz to 200 MHZ continuous!!!
ICOM does not warranty these mods.
More talk power on SSB from your Icom 706Mk2/Mk2G and Alinco DX70TH
The following adjustments are to increase the average talk power on SSB for the above radios. If your radio is still under warranty,
check with your supplier to ensure warranty will not be invalidated
For both these adjustments you will need a very small cross-point screwdriver and a steady hand! Do not proceed if you are not
confident!
Alinco DX70TH: Turn up the microphone gain as detailed in the manual. This should be set to maximum. The adjustments
described here is concerned with the ALC control. ALC action is indicated by the TX light which should glow brighter when
speaking into the microphone.
