S2E-17-0056_A
INSTALLATION
MANUAL
WEATHER RADAR
MODEL:
WR110
TYPE:
www.furuno.com

Advertisement

Table of Contents
loading

Related Manuals for Furuno WR110

Summary of Contents for Furuno WR110

  • Page 1 S2E-17-0056_A INSTALLATION MANUAL WEATHER RADAR MODEL: WR110 TYPE: www.furuno.com...

  • Page 2: Safety Instructions

    S2E-17-0056_A SAFETY INSTRUCTIONS The user and installer must read the appropriate safety instructions before attempting to install or operate the equipment. Indicates a hazardous situation which, if not avoided, will result DANGER in death or serious injury. Indicates a potentially hazardous situation which, if not WARNING avoided, could result in death or serious injury.
  • Page 3 POWER CONSUMPTION: MAX Watt RATED AMPERE WR110 restrictions There are restrictions frequency band as follows to use at Lithuania and Slovakia. WR110 is operated with a channel from the following four channels: CH1: 9422.5MHz, CH2: 9427.5MHz, CH3: 9432.5MHz, CH4: 9437.5MHz...

  • Page 4: Table Of Contents

    1. System Summary ......... 1 10.2. Data Processing Unit ..... 43 2. Equipment Configuration 11. UPS settings 2.1. Standard Equipment of WR110 .... 3 11.1. APC product ........44 2.2. Optional accessories for installation ..4 11.1.1. Login ........45 2.3.

  • Page 5: System Configuration

    S2E-17-0056_A System Configuration The observation system consists of an Antenna Unit (radome), a Signal Processing Unit (connection box) , and a Data Processing Unit (indoor unit) are shown below. (1) Antenna Unit (radome) (2) The antenna, stored in the radome, turns to radiate the radio waves. The radiated waves are backscattered by precipitation particles on the propagation path, return to the antenna, and are processed by RF converter to transfer the signals to the Signal Processing Unit .

  • Page 6: System Summary

    S2E-17-0056_A 1. System Summary This system observes the development of rain clouds, outputs the strength of precipitation and the speed of rain clouds (Doppler speed), and observes phenomena of rainfall. Features: 1. While installing antenna on a rooftop of building in urban area, it must be installed in the safety area covered by lightning rod based on JIS A4201 and IEC61024-1.
  • Page 7 S2E-17-0056_A Sample image of WR-2100 Indonesia Indonesia Denmark Belgium...

  • Page 8: Equipment Configuration

    S2E-17-0056_A 2. Equipment configuration MODEL TYPE WEATHER RADAR WR110 2.1. Standard Equipment of WR110 Main Unit Items Units Descriptions Size : Ф980mm×H1068mm (include radome) Weight : 65Kg Antenna Unit WR110 -ATU Weight of radome only: Upper 15kg (incl. 12pcs of M10x35 stopper hexagon bolt), Bottom 11kg Size: W330 x D130x H336mm (connection box) Weight: 2.0kg...

  • Page 9: Optional Accessories For Installation

    Ratchet Wire Crimper 2sq For electric wiring work LAN cable strippers For LAN cable work LAN Ratchet Crimper For LAN cable work LAN cable tester For LAN cable work 2.4. Overall appearance Refer to the APPENDIX for Drawing of WR110...

  • Page 10: Prior Confirmation

    S2E-17-0056_A 3. Prior confirmation 3.1. Confirmation items 1. The mount plate must be installed properly for Antenna Unit (radome). 2. Power cable (AC100V-240V) must be laid safely. 3. Power cable thickness should be selected depends on its length. 4. Frequency of AC power source must be 50Hz or 60Hz sin wave and single-phase current. 5.

  • Page 11: Peripherals Equipment

    S2E-17-0056_A 3.5. Peripherals equipment The purposes of using these peripherals are for remote control: 1. Wired router Function Connect with an external network WAN port 10/100/1000BASE-T, 1 port, MDI/MDI-X auto switch LAN port 10/100/1000BASE-T, 4 port or more, MDI/MDI-X auto switch Input voltage AC100V-240V, Single phase, 50/60 Hz Remarks...

  • Page 12: Precautionary Item

    S2E-17-0056_A 4. Precautionary item 1) Use only the commercial power supply of single phase 100-240VAC. 2) DO NOT overhaul or remodel. 3) DO NOT work during the thunder is occurring. 4) DO NOT scratch, cut, forcedly bend, pull, twist, bundle, or damage the power cable. Also, not to put a heavy thing on top or interpose.

  • Page 13: Construction

    S2E-17-0056_A 5. Construction All installation places will be considered for installing DPU, cables, pipes, and mount plate during the environmental survey. 5.1. Antenna Unit <Case 1> A way of using a frame stands to mount the Antenna Unit. Use 4 pieces of M16x200 Bolts to adjust a level while join and fix the lifting tool and a frame stand. Base plate M16 bolt Radome...
  • Page 14 S2E-17-0056_A 1. Levelling the Antenna Unit Fig. 5-2. M16 bolt *1: These hex nuts, flat washers, split lock washers are attached with the lifting tool (optional). Check with the bubble level under the radar to turn M16 hex nut (Fig.5-2) for adjusting Fig.
  • Page 15 S2E-17-0056_A After leveling the radar, make sure to confirm every four nut touches to the top of the stand before pinching the stand from the bottom, i.e. between ①nut, ②XL flat washer, and ③radar stand are not having gap before tighten the ④nut, in order not to strain the radome and stand. ①nut ②XL flat washer ③Radar stand...
  • Page 16 S2E-17-0056_A 2. Connect LAN cable for MONI-CON and SPU MONI-CON LAN connector SPU LAN connector 3. Wire the power filter Caution: Make sure an electric current is not flow (1) Fix / Connect AC power cable (3pin) (2) Confirm the circuit diagram of power filter label before connecting.
  • Page 17 S2E-17-0056_A 4. Insert the outdoor cable into the protecting tube (2 pcs). Protecting Tube 1: - C1: AC Power cable (3cores) - C2: LAN cable x2 Protecting Tube 2: Cover by cap ※ Fix cables tight by cable ties with having extra cable length after connected cables.
  • Page 18 S2E-17-0056_A 7. Specification of the protecting tube connector. Gasket Tube Lock Gasket ① Remove a cap. ② Protecting tube Cut protecting tube neatly Do not leave this kind of projection ③ Gasket...

  • Page 19: Junction Unit

    S2E-17-0056_A 5.2. Junction Unit 1. AC power connection Connect the power cable from ATU to the terminal block (T1-3), and connect the power cable from DPU to the terminal block (T5-7). Caution: Do not plug in or turn on the power RJ45 breaker (DPU side) at this moment.

  • Page 20: Open The Radome Temporary

    S2E-17-0056_A 5.4. Open the radome temporary This is the instruction to open radome temporary by using bolts to fix top radome for maintenance work. One set of tension bolt (4 bolts) is in the rack. Fix these bolts by putting into hole of top and bottom radome and make sure to take a balance as shown below: Caution: DONOT open a top radome during strong wind.

  • Page 21: Operation Test

    S2E-17-0056_A 6. Operation Test Follow the step as below: 6.1. Before cover (Top part of radome) (1) Check azimuth offset by GPS, compass, or some measurement. (2) Turn ON the power of DPU User name: radar Password: radar (3) Stay away from radar farther than 12.7m *It might cause a damage to the human body, especially to eyes if receiving the transmit radio wave directly in short distance.

  • Page 22: After Cover

    S2E-17-0056_A 6.2. After cover (Top part of radome) (1) Make sure the power of all JCU and DPU are ON. (2) Open the RainMap software to start the [Radar Operation] to [Connect] (3) Start [TX] under the [Radar Operation] menu to acquire the data. Complete...

  • Page 23: Install Teamviewer

    And then click [OK] and then click [Exit] 123 456 789 3. After installed software, please inform “Your ID” to the headquarter of Furuno who is in charge. 4. Use other PC to confirm the connection of TeamViewer by remote access.
  • Page 24 S2E-17-0056_A 5. The following instruction is Setup security on TeamViewer Host if necessary. * Please confirm to a customer and Furuno Headquarter before setup. (1) Right click to the icon of TeamViewer in task bar. (2) [TeamViewer options] will indicate a Popup menu on a screen after clicked [Option] from dropdown list of TeamViewer.

  • Page 25: Dpu Operation

    S2E-17-0056_A 8. DPU operation (*1) : Click Menu + press ([Ctrl] + [Alt]) keys simultaneously to indicate the hidden service menu. 8.1. File Operation mode(*1): Do this operation mode after changed some parameters to operate the radar. - Observation: Select the entered values at “Setting” menu with regular mode.

  • Page 26: Setting

    S2E-17-0056_A 8.3. Setting 8.3.1. Setting 1) Display Display range [km] Setup an indication range. Display data type Select an indication of the radar parameter. ・ R [mm/h]: Intensity of rainfall [mm/h] ・ Zh [dBz]: Reflection factor of the horizontal polarimetric radar ・...
  • Page 27 S2E-17-0056_A Radar parameters in Binary file Choose a type of parameter: R [mm/h], Zh [dBz], V [m/s], W [m/s], Quality 3) Radar Site Location Latitude [deg] Setup the latitude of the installed point. Longitude [deg] Setup the longitude of the installed point. Altitude [m] Setup the altitude of the installed point.
  • Page 28 S2E-17-0056_A Sector RHI scan: EL rotation speed [rpm] Setup an elevation speed of Sector RHI. AZ start angle [deg] Setup an angle of start azimuth range. AZ end angle [deg] Setup an angle of end azimuth range. AZ step angle [deg] Setup a quantity of antenna rotation while changing an angle of azimuth.
  • Page 29 S2E-17-0056_A EL angle 0 – 31 [deg] Setup each elevation variation, up to 32 different values. It automatically sorts in ascending order of elevation setting value. Sector PPI scan: AZ rotation speed [rpm] Setup an azimuth rotation speed at fixed azimuth angel.
  • Page 30 S2E-17-0056_A Ending point to Ending point to observe elevation observe elevation Vertical Vertical direction direction Counter clockwise Ending point to Ending point to Starting point to Starting point to Horizontal observe azimuth observe azimuth observe elevation observe elevation direction Starting point to Starting point to Horizontal Clockwise...

  • Page 31: Service

    S2E-17-0056_A 5) Units Rotation speed Select a type of indication on rotation speed. 8.3.2. Service Press [Ctrl] + [Alt] and click [Setting] simultaneously to indicate service menu. Service menu has two types: 1. Maintenance setting: Regular menu for maintenance service engineer. 2.
  • Page 32 5) Network SPU type Select and setup the SPU channel of the ATU. Manual / Auto (Automatically select type of radar either WR110 or WR2120) Command transfer IP Confirm the IP address of command transfer.  Constant value: 192.168.31.101 Command transfer port Confirm the port number of command transfer.
  • Page 33 S2E-17-0056_A EL start angle [deg] Setup the starting angle of elevation to make a sector blank. EL end angle [deg] Setup the ending angle of elevation to make a sector blank. 9) Ground Clutter Rejection Turn 1, 2, or OFF Select whether to remove ground clutter as a target if moving speed is lower than setting speed.

  • Page 34: Precipitation Estimates Methods

    S2E-17-0056_A 8.3.3. Precipitation estimates methods: Zh method 1. Use standard Marshal Palmer equation; 2. Parameters “B” and “β” are able to set by maintenance interface. Default value of “B” is 200, and ”β” is 1.6. 3. Zh unit is using mm /mm.

  • Page 35: Management List

    S2E-17-0056_A 8.3.4. Management list The management list would be attached with the RainMap to every location for setting. ・ Please setup some values that belong to the location. ・ Default value of each equipment is listed on a separate sheet. ・...
  • Page 36 S2E-17-0056_A 2. Service Service menu will come out when pressed [Alt]+[Ctrl]keys and clicked [Setting] menu simultaneously.

  • Page 37: Radar Operation

    S2E-17-0056_A 8.4. Radar Operation 1. Turn on the power of Data Processing Unit 2. Software will start automatically. 3. Click [Connect] button to start radar operation. [Connect] will be indicated in the left bottom. 4. Click [TX] button to start observation. 5.

  • Page 38: Help

    S2E-17-0056_A (1) Setup a number of times for scenario: Setup a number of time to scan from 10 to 60 (Large scan number could receive higher accuracy). (2) Confirm to start measurement: Click [OK] to begin when it is ready. Click [Cancel] to quit measurement.

  • Page 39: Rainplay Operation

    S2E-17-0056_A 8.7. RainPlay operation RainPlay will indicate after selecting [File play] on RainMap. It could also possible to use RainPlay.exe from “RainMap_RainPlay” folder on desktop even during RainMap is activating. File File play: Select files of log data (*.scn; *rhi, sppi scnd, rhid, sppid) to play (Slide show) on screen Print: ・Main screen: Printout the main screen...
  • Page 40 S2E-17-0056_A Setting Scale: Setup a distance of scale into a pop-up window of [Scale] Azimuth offset: Setup a degree of offset into a pop-up window of [Azimuth Offset] Disp Select： Select an indication of data type： - Rain： Intensity of rainfall - Zhh：...
  • Page 41 S2E-17-0056_A Play Start： Start playing a log data Stop： Stop playing Pause： Pause playing Fast Forward： Fast forward playing Rewind： Rewind playing Time display： Popup a setup windows Setup a time display [between 1000 - 10,000 ms] List view: To show a play list on the right screen Snapshot Main screen: Copy a main screen and select a place to save a...

  • Page 42: Initial Setting Of Azimuth

    S2E-17-0056_A 8.8. Initial setting of Azimuth The real geographical feature and azimuth are different with the initial echo indication, therefore it has to make an adjustment. At first, it has to setup “Azimuth Offset” in RainMap software by measuring the azimuth at origin. It generally uses a magnetic compass, GPS compass, or the solar measure tool.
  • Page 43 S2E-17-0056_A <Image screen> 1. Setup an Antenna elevation a little higher to 5 degree. 2. Make only the higher mountain that can be seen by echo instead of surrounding buildings. 3. Infer a correct echo indicate azimuth from characteristic echo and a location of mountain map.

  • Page 44: Log File Function

    S2E-17-0056_A 8.9. Log file function 1) Abnormal information It indicates error information up to 50 on the screen. It will overwrite when it goes over 50 and those logs will save into log file (in the same folder of RainMap.exe). Log record: Log record folder will be created automatically in to RainMap folder and to save log data [log]...

  • Page 45: Menu Tree

    S2E-17-0056_A 9. Menu Tree RainMap (*1) Menu [File] Menu [Operation mode] [Observation] [Verify operation during installation] [File Play] [Snapshot] (*1) [SPU Shutdown] [Exit] Menu [Disp] [SRHI screen] [90 deg screen] [180 deg screen] [Information indication] [Pulse spec…] [Abnormal information] Menu [Setting] [Service screen menu] (Ref.
  • Page 46 S2E-17-0056_A RainPlay Menu [File] [Open] [Print] [Main screen] [SRHI screen] [Exit] Menu [Setting] [Model] [Large] [Scale] [Small] [Azimuth Offset] Menu [Disp] [Select] [Rain] [View] [Zhh] [Ratio of transparency] [0%] [Zdr] [25%] [Kdp] [50%] [75%] [dp] [Map] [100%] [hv] [SRHI screen] [90 deg screen] [180 deg screen] [Invalid data area]...

  • Page 47: Specification

    S2E-17-0056_A 10. Specification 10.1. Antenna Unit Parameter Descriptions Remarks Transmit Frequency 9.4 GHz band Occupied Band Width 40 MHz or less Displayable scale level: Maximum distance 70km 0.5 to 70km Max. ±64m/sec Doppler measurement 100 to 240VAC, Single Phase, Power supply 50/60 Hz Power consumption Max.

  • Page 48: Data Processing Unit

    S2E-17-0056_A 10.2. Data Processing Unit Receive data from Junction Unit (JCU) to indicate a picture of rainfall in real time. Hardware Parameter Descriptions Power supply 100 to 240VAC, 50/60Hz Power consumption Max. 150W Temp. range 0 to +50 °C User Interface For weather observation system Software RainMap, RainPlay...

  • Page 49: Ups Settings

    S2E-17-0056_A 11. UPS settings 11.1. APC product This procedure is only for Smart-UPS 1500RM model, it picked up only for some main points Setup on software of “Power Chute”. General Power High Transfer [V] Parameters Low Transfer [V] Sensitivity High Nominal Output [V] 220 Audible Warning On Battery...

  • Page 50: Login

    S2E-17-0056_A 11.1.1. Login Power Chute would be popup after start DPU. User Name: radar Password: radar Server: 127.0.0.1 Click [Connect] to login. 11.1.2. Power Protection Strategy Preserve Battery Power: 1) Open configuration profile: 2) Click [Power-Protection Strategy] tab: [Tools] -> [Change Configuration Profile] Put a check on [Preserve battery power] Power Parameter: 1) Right click at [WR110_xxxx] to open device...
  • Page 51 S2E-17-0056_A 2) Put a check on [Show advanced items] to indicate more items trees. 3) Click [Power Parameter] Setup the power settings: High-Transfer Voltage: 265 Low-Transfer Voltage: 196 Sensitivity: High Nominal Output Voltage: 220 Audible Warning: On Battery Shutdown Sequence 1) Click [Server Shutdown] ->...
  • Page 52 S2E-17-0056_A 4) Setup [Operating System] as follows: - Delay: 0:00:00 - Duration: 0:01:30 5) Click [Next] to save it 6) Click [Finish] to close shutdown sequence Power Failure 1) Click [Server Shutdown] -> [Power Failure] Setup as follows: When power fails, begin a shutdown procedure: At runtime limit When power returns, reboot UPS:...

  • Page 53: Windows Language Settings

    S2E-17-0056_A 12. Windows Language setting Notice: The DPU display language must set to Japanese to upgrade the FWR software. the program will be upgraded in the near future so that the language change to Japanese is no longer necessary. The DPU must be able to change display language from English to Japanese. RainMap and Power Chute (UPS software) menus and indications automatically change language.
  • Page 54 S2E-17-0056_A 5. Setup [Region] - Click the [Administrative] tab. - Click the [Copy settings…] button in the [Administrative] tab to show the [Welcome screen and new user accounts settings].. - Put a check on “Welcome screen and system accounts”, and “New user accounts” at “Copy your current settings to:”.
