Panasonic TH-86SQE1W Operating Instructions (Functional Manual)

Panasonic TH-86SQE1W Operating Instructions (Functional Manual)

Uhd

Advertisement

Engl�sh
Engl�sh
EU
TP0819TS0 -PB
TH-86SQE1W - TH-86CQE1W
Model No.
TH-75SQE1W - TH-75CQE1W
TH-65SQE1W - TH-65CQE1W
TH-55SQE1W - TH-55CQE1W
TH-49SQE1W - TH-49CQE1W
TH-43SQE1W - TH-43CQE1W
Read before use
For more �nformat�on about th�s product, please read the "Operat�ng
Instruct�ons – Funct�onal Manual".
To download the "Operat�ng Instruct�ons – Funct�onal Manual", please
v�s�t the Panason�c webs�te (https://panason�c.net/cns/prod�splays/).
• Please read these �nstruct�ons before operat�ng your set
and reta�n them for future referance.
• Illustrat�ons and screens �n th�s Operat�ng Instruct�ons are
�mages for �llustrat�on purposes, and may be d�fferent from
the actual ones.
• Descr�pt�ve �llustrat�ons �n th�s Operat�ng Instruct�ons are
created ma�nly based on the 75-�nch model.
Operat�ng Instruct�ons
UHD LCD D�splay For bus�ness use
Funct�onal Manual
86-�nch model
75-�nch model
65-�nch model
55-�nch model
49-�nch model
43-�nch model
*Actual resolut�on:
3840 × 2160p

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TH-86SQE1W and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic TH-86SQE1W

  • Page 1 Operat�ng Instruct�ons Funct�onal Manual UHD LCD D�splay For bus�ness use TH-86SQE1W - TH-86CQE1W Engl�sh Model No. 86-�nch model TH-75SQE1W - TH-75CQE1W 75-�nch model TH-65SQE1W - TH-65CQE1W 65-�nch model TH-55SQE1W - TH-55CQE1W 55-�nch model TH-49SQE1W - TH-49CQE1W 49-�nch model TH-43SQE1W - TH-43CQE1W 43-�nch model...
  • Page 2: Table Of Contents

    Dear Panasonic Customer Media Playback via USB Input......19 Welcome to the Panasonic family of customers. We CEC and CEC RC Passthrough......20 hope that you will have many years of enjoyment Audio Return Channel..........20 from your new LCD Display. To obtain maximum benefit from your set, please read these Instructions Settings Menu Content...........21...
  • Page 3: Before Use

    • Unplug your product before starting to clean. Do not clean the product when it is on. Do not use WARNING liquid or aerosol cleaners. Use a damp cloth for RISK OF ELECTRIC SHOCK cleaning. If that does not help, please use LCD DO NOT OPEN display cleansers.
  • Page 4 • For permanently connected equipment, a readily • The wireless LAN feature of this display shall exclusively be used inside buildings. accessible disconnect device shall be incorporated in the building installation wiring. • Be sure to disconnect all cables and overturn prevention accessories before moving the Display.
  • Page 5 Safety checks disconnecting cables. Also, read the manual of the equipment to be connected. Upon completion of service or repair work, request the service technician to perform safety checks to ensure Be careful not to confuse the input terminal with the that the product is in proper operating condition.
  • Page 6: Fcc Statement

    This device complies with Part 15 of the FCC Rules power supply cord. Any changes or modifications and all applicable IC RSS standards. Operation not expressly approved by Panasonic Corp. of North is subject to the following two conditions: (1) This America could void the user’s authority to operate device may not cause harmful interference, and (2) this device.
  • Page 7: Important Safety Notice

    This is A replacement fuse cover can be purchased from not a malfunction. your local Panasonic dealer. • This unevenness will disappear while applying Do not cut off the mains plug. current continuously. If not, consult the distributor.
  • Page 8: Battery Safety Guidelines

    • Change your password periodically. • Never attempt to recharge ordinary batteries, either • Panasonic Corporation or its affiliate companies will in a charger or by applying heat to them. They may never ask for your password directly. Do not divulge leak, cause fire or even explode.
  • Page 9: Disposal

    To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: Please contact Panasonic if you need help taking care HDMI input terminal, D-sub input terminal and RS- of security settings or other such.
  • Page 10: Accessories Included

    • JavaScript is a registered trademark or a Mass trademark of Oracle Corporation and its Approx. 111 g. (4 oz) including subsidiary and associated companies in the batteries United States and/or other countries. Dimensions (W x H x D) 51mm x 27mm x 161mm / •...
  • Page 11: General View

    General View Front Side 1. LCD Panel Rear Side (1) SQE1 CQE1 13 14 HDMI IN HDMI IN D splayPort AUDIO AUDIO IR IN IR IN HDMI IN HDMI IN 1.5A 0.5A 0.5A SERIAL IN PC IN USB-C 1. SERIAL IN 12.
  • Page 12: Control Buttons On The Display

    Rear Side (2) DIGITAL AUDIO AUDIO SERVICE 2 SERVICE 1 1. DIGITAL AUDIO OUT 2. AUDIO IN 3. RJ12 (SERVICE 1) 4. RJ12 (SERVICE 2) Note : Don’t use except service personnel for RJ12. Control Buttons on the Display To turn on the Display: Press the centre of the joystick in and hold it down for a few seconds, the Display will turn on.
  • Page 13: Connecting The Ir Receiver

    Connecting the IR Receiver Before plugging the Display into the mains supply, connect the supplied IR receiver to the IR input on the Display. Place the IR receiver in sight of your own remote control. Simply operate your remote control whilst pointed at the IR receiver and it will relay the control signal to your Display.
  • Page 14: Remote Control

    Remote Control 14. INPUT : Switches input to display on the screen 15. MENU: Displays the main menu 16. RETURN: Returns to previous screen 17. ENTER: Confirms user selections 18. RECALL: Displays information about on-screen content 19. Stop: Stops the media being played 20.
  • Page 15: Caution For Ac Cord

    CAUTION for AC CORD 86-inch model Back of the unit 86-inch Model 75-inch Model AC Cord Fixing 65/55/49/43-inch Model AC Cord (Supplied) Note • When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet first. •...
  • Page 16: Fixing The Ir Sensor

    Fixing the IR Sensor 43/49/55/65/75 inch Attachment of sensor and holder Fix the sensor to holder. Tighten two screws Connect sensor cable to IR IN (Back View) (Front View) Sensor Holder Two Screws 86 inch (Back View) Attachment of sensor and holder Remove the five screws.
  • Page 17: Attaching The Function Slot

    Attaching the Function SLOT (For SQE1W) Remove the two screws and the main unit slot cover. Insert the function board to the main unit slot. Tighten the two screws. Narrow-width function board Wide-width function board English - 16 -...
  • Page 18: Cautions When Moving

    Cautions When Moving The display has handles for carrying. Hold them when moving. 86-inch model Handle 75-inch model Handle Note • Do not hold parts other than the handles. (86-inch model, 75-inch model) • The following number of peaple are required to carry this unit. 86-inch model 75-inch model, 4 or more 75-inch model, 65-inch model, 55-inch model, 49-inch model, 43-inch model: 2 or more If this is not observed, the unit may drop,resulting in injury.
  • Page 19: Shipping

    Shipping Using Main Display Menu When turned on for the first time, the language selection screen will be displayed. Select the desired language and press ENTER. When the Menu button is pressed, the main Display menu will appear at the left of the screen. You can On the next screen, set your country preference and navigate through the menu items using the directional press ENTER to continue.
  • Page 20: Media Playback Via Usb Input

    compatible. Set accordingly or disable the HDMI button while playing back a video file or displaying source by setting as Disabled. a picture file. Press the RECALL button, highlight the gear wheel symbol positioned on the right side You can reset your customizations on the Home and of the information bar and press ENTER.
  • Page 21: Cec And Cec Rc Passthrough

    //**do usb auto play**// hold the “0-Zero” button on the remote control for 3 seconds. picture.jpg You can disable the CEC functionality by setting the video.mp4 related option under the Settings>System>More picture2.jpg menu accordingly. /*picture3.jpg*/ Audio Return Channel video2.mp4 Scheduler playlist scenario In this scenario, if the Source option is set as USB The Display supports ARC (Audio Return Channel).
  • Page 22: Settings Menu Content

    Settings Menu Content Menu that cannot be adjusted is greyed out or hidden. Adjustable menu changes depending on signal, input and menu setting Picture Menu Content You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Text, Game, Sports, Signage and Natural.
  • Page 23 Edge Smoother setting allows you to adjust the edge smoothness. Edge Smoother Off, Low, Medium, High Auto Setup: When inputting a PC signal, [H position] / [V position], [Dot Clock] and [Clock Phase] are automatically corrected. H position: Adjust the horizontal position. V position: PC Position Adjust the vertical position.
  • Page 24 Start a speed test to check your connection bandwidth. The result will be displayed Internet Speed Test on the screen when finished. Advanced Settings Change the IP and DNS configurations of your Display. Wake On Enable or disable this feature by setting it as On or Off. Administrator Configure the administrator account settings.
  • Page 25 Sets the various items for SNMP. SNMP (Simple Network Management Protocol) is a protocol to manage devices connected to the network. If the SNMP manager is used for connection, the information of the target device can be obtained, and its settings can be changed. [Snmp Username]: Enter the user name of SNMP v3.
  • Page 26 Sets the behavior preference of the Display, when no signal is detected from the currently set input source. Image Search and Input Search options are available. If Image Search is selected the Display checks the connected USB device for available files to play.
  • Page 27 If this feature is enabled the Display can be turned on again with the RS232 and LAN commands if it is turned off through it. Press Left or Right button to enable or disable the feature. The Quick standby turns on the power quickly when the power is turned on. Quick Standby ON: The power is turned on quickly when the power is turned on.
  • Page 28 Clone to USB Copies the database files from the unit to a connected USB device. Clone from USB Copies the database files from a connected USB device to the unit. Copy app cache Copies app cache data from a connected USB device to the unit. from USB Note: This feature may not be available depending on the model of your unit.
  • Page 29 Press ENTER to open the SLOT Settings menu screen. Three sub-menu options are available. SLOT Status: Displays whether the SLOT module is on or off. Allows the change of status via soft PSON signal (0.5s) Boot Signal: Enables or disables sending of a PSON signal. The Display checks the status signal of the SLOT at bootup in order to turn it on by sending a PSON signal if it is off.
  • Page 30 Using the scheduler options you can set the unit to turn on automatically at defined time intervals with the defined input source setting on the desired days of the week. Press ENTER to open the Scheduler Settings menu screen. You can set up to 4 different schedulers.
  • Page 31 System Menu Content Language Sets the OSD menu language preference. Date/Time Sets date and time. Enables or disables selected source options. There will be Regular, Enhanced and Disabled options available for HDMI sources, if your Display supports Ultra HD. Regular and Enhanced options are affecting the colour settings of the selected HDMI source.
  • Page 32: Connectivity

    Other Information HDMI cable. When inputting video signals exceeding the transmission speed supported by the HDMI You can also enable or disable Wake On feature using cable you are using, malfunction may occur such as the related option. The status of the connection will interrupted pictures and no display on the screen.
  • Page 33: Wireless Connectivity

    Configuring Wireless Device Settings pipe, of which is grounded at both ends. Open the Network menu and select Network Type as Wireless Device to start connection process. Wireless Connectivity Highlight Scan Wireless Networks option and press ENTER to start a search for available wireless networks.
  • Page 34: Wireless Display

    device, from which the network message will be sent the production of this Display. Scanning and connecting processes differ according to the programme you use. The to the Display, and the Display are connected to the maximum supported resolution is 1920x1080. Image quality same network.
  • Page 35: Apps

    this causes your problem, contact your internet the ENTER button to see available page specific and service provider. A firewall might be the reason of a general options. connectivity problem. There are various ways to search or visit websites using the web browser. Apps Enter the address of a website(URL) into the search/ address bar and highlight the Submit button on the...
  • Page 36: Usb-C

    To be able to stream the same image to all connected time information. If the NTP server update fails, the Displays using a MST compliant device, DisplayPort Display uses RTC time and date to update itself. Stream Setting option in the Settings>System>More •...
  • Page 37: Control Command Via Lan

    ETX signal in that order. Add require parameter, a colon (:) is not needed. parameters as required according to control details. • Consult your local Panasonic dealer for detail instructions on command usage. For more details, visit the following web site. C1 C2 P1 P2 P3 P4 P5 https://panasonic.net/cns/prodisplays/...
  • Page 38 : [Network] – [Administrator Account] – [User Name] • Consult your local Panasonic dealer for detail instructions on command usage. yyyyy : [Network] – [Administrator Account] – [Password] For more details, visit the following web site.
  • Page 39: Pjlink Protocol

    PJLink protocol The unit’s Network function is compatible with PJLink Class 1 & Class 2. The following operations can be performed from a computer when PJLink protocol is used. • Setting the Display • Querying the Display status PJLink security authentication Set the password used for PJLink on the dialog accessible through [PJLink password].
  • Page 40: Preset Signals

    Preset Signals This unit can display the video signals shown in the table below. The contents of HDMI signal in the Plug and Play- supported signal column are as follows. Scanning Frequency Plug and Play supported signal Dot Clock Corresponding Resolution (Dot) frequency Format*2...
  • Page 41 640x480/85 640 x 480 43,27 85,01 H/DP/TypeC/VGA 800x600/56 800 x 600 35,16 56,25 H/DP/TypeC/VGA 800x600/60 800 x 600 37,88 60,32 H/DP/TypeC/VGA ○ ○ ○ ○ 800x600/72 800 x 600 48,08 72,19 H/DP/TypeC/VGA 800x600/75 800 x 600 46,88 49,5 H/DP/TypeC/VGA 800x600/85 800 x 600 53,67 85,06...
  • Page 42 1600x900/60 1600 x 900 H/DP/TypeC ○ 1600x900/60 1600 x 900 55,99 59,95 118,25 H/DP/TypeC 1600x900/60 1600 x 900 55,92 H/DP/TypeC 1600x1200/60 1600 x 1200 H/DP/TypeC/VGA ○ 1680x1050/60 1680 x 1050 65.29 59.95 146.25 H/DP/TypeC 1920x1080/60 1920 x 1080 66,59 59,93 138,5 H/DP/TypeC 1920x1080/60...
  • Page 43: Supported Media Formats From Usb

    Supported Media Formats From USB Video File Formats Video Codec Resolution Bit Rate Container MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG MPEG1/2 transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), MPEG4 1080P@60fps...
  • Page 44 AC3 (.ac3), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp, 32KHz, 44.1KHz, 32Kbps ~ .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp, 48KHz 640Kbps .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG) EAC3 (.ec3), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a), 32KHz, 44.1KHz, 32Kbps ~ 6 EAC3...
  • Page 45 Wireless LAN Transmitter Specifications Max Output Frequency Ranges Power 2400 - 2483,5 MHz (CH1-CH13) < 100 mW 5150 - 5250 MHz (CH36 - CH48) < 200 mW 5250 - 5350 MHz (CH52 - CH64) < 200 mW 5470 - 5725 MHz (CH100 - CH140) <...
  • Page 46: Specifications

    ,16:9 aspect ratio 65CQE1 : 65-inch VA panel (Direct LED backlight) Power Consumption ,16:9 aspect ratio 55- Inch Model 55-inch IPS panel (Direct LED backlight), TH-86SQE1W 364W (3.6-1.8A) 16:9 aspect ratio 86- Inch Model TH-86CQE1W 364W 49- Inch Model (3.6-1.8A)
  • Page 47 Dimensions (W x H x D) 75- Inch Model 75SQE1:37.4kg / 82.5lbs net 75CQE1:36.8kg / 81.2lbs net 86- Inch Model 86SQE1:1929x1100x81 (top of VESA NUT:55) 65- Inch Model 65SQE1:25.8kg / 56.9lbs net (including remote controller sensor:1116mm) 65CQE1:25.2kg / 55.6lbs net 75.91"...
  • Page 48 Operating Time For network connection, compatible with PJLink Communication method ; RJ45, 10BASE- 24hours/day (SQE1W) T/100BASE-TX 16hours/day (86/75/65/55/49/43CQE1W) ................... Sound IR IN Stereo mini jack (M3) 86-Inch 75-Inch ................... Model Model SPDIF Optical Out port 24W [12W + 12W)] (10% THD) ...................
  • Page 49: Troubleshooting

    Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Check Picture Sound Electrical Appliances Cars / Motorcycles Fluorescent light Interference Noise Sound Volume (Check whether the mute function has been activated on the remote control.) Audio input MP3 terminal (No sound will be output from the set speakers if connected.)
  • Page 50 Symptoms Check Check the settings of No Signal Power Off, [HDMI1 Wake UP], Power automatically turns off [HDMI2,3,4 Wake UP, and No Activity Power Off. Any of them may be unexpectedly. set to [On(Enable)]. (see page **) Can not turn on. There is possibility of malfunction.
  • Page 51 Symptoms Check Check that the connection has been made properly. Check that [Network] is set properly. Check whether the [Administrator Account] is configured. The LAN is uncontrollable The control with command control, check that [Settings] - [Network] - [Command control] is set to [ON]. When connecting to a device of Crestron Electronics, Inc., set [Crestron Connected™] according to the device to use.
  • Page 52: Mounting The Display

    There is convex shape near VESA holes on back cover. When attaching wall mount or stand, insert the spacers between them. Convex Shape Spacer Note : For detailed dimensions, please refer to the CAD drawings on Panasonic website. English - 51 -...
  • Page 53: Installation On An Indented Wall

    Installation On An Indented Wall Operation of this unit is guaranteed up to an ambient temperature of 40ºC(104ºF). When installing the unit in a case or chassis, be sure to provide adequate ventilation with a cooling fan or ventilation hole so that the surrounding temperature (inside the case or chassis) including the temperature of the front surface of the liquid crystal panel can be kept at 40ºC(104ºF) or less.
  • Page 54: Cautions For Portrait Setting

    Cautions for portrait setting When installing the display vertically, be sure that the terminals come to up for 75/65/55/49/43SQE1 and comes to down for 86SQE1. 75/65/55/49/43-inch Terminals 86-inch Terminals Note When installing the pedestal or wall hanging bracket, read the operating instructions supplied with it carefully and install properly.
  • Page 55: Software License

    [Settings] menu of this product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0,...
  • Page 56: Service Centre

    Unit of Panasonic Corporation of North America Executive Office : Two Riverfront Plaza, Newark, New Jersey 07102 Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, F.R. Germany Panasonic Corporation English Web Site: http://panasonic.net/cns/prodisplays/ ©...
