TH-86EQ2W
Model No.
TH-75EQ2W
TH-65EQ2W
English
Read before use
For more information about this product, please read the "Operating
Instructions - Functional Manual".
To download the "Operating Instructions - Functional Manual", please
visit the Panasonic website (https://panasonic.net/cns/prodisplays/).
Please read these instructions before operating your set and retain
•
them for future reference.
Illustrations and screens in this Operating Instructions are images for
•
illustration purposes, and may be different from the actual ones.
Descriptive illustrations in this Operating Instructions are created
•
mainly based on the 55-inch model.
EU
TP0322TS0 -PB
Operating Instructions
UHD LCD Display For business use
TH-55EQ2W
86-inch model
TH-50EQ2W
75-inch model
TH-43EQ2W
65-inch model
Contents
Basic Guide
Important Safety Instructions ····················· 2
FCC STATEMENT ·································· 3
Important Safety Notice ···························· 4
Safety Precautions ·································· 6
Precautions for use ································· 9
Accessories ········································· 12
Cautions when moving ·························· 16
Kensington security ······························· 16
Eyebolt ············································· 17
Connections ········································ 18
Identifying Controls ······························· 22
Basic Controls ······································ 25
Specifications ······································ 27
Software License ·································· 30
Limited Warranty ·································· 31
LIMITED WARRANTY STATEMENT ········· 32
DPQX1613ZA/X1
55-inch model
50-inch model
43-inch model
*Actual resolution:
3840 × 2160p
Advertisement
Table of Contents
Related Manuals for Panasonic TH-86EQ2W
Summary of Contents for Panasonic TH-86EQ2W
-
Page 1: Table Of Contents
For more information about this product, please read the “Operating Instructions – Functional Manual”. To download the “Operating Instructions – Functional Manual”, please visit the Panasonic website (https://panasonic.net/cns/prodisplays/). *Actual resolution: 3840 × 2160p Please read these instructions before operating your set and retain •... -
Page 2: Important Safety Instructions
Important Safety WARNING Instructions WARNING: To reduce the risk of electric shock, do not remove cover or back. 1) Read these instructions. No user-serviceable parts inside. Refer servicing 2) Keep these instructions. to qualified service personnel. 3) Heed all warnings. 4) Follow all instructions. -
Page 3: Fcc Statement
However, it will disappear when power supply cord. Any changes or modifications a general moving picture is displayed for a while. not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate Trademark Credits this device. -
Page 4: Important Safety Notice
Important Safety IMPORTANT INFORMATION: Stability Hazard Never place a display in an unstable location. A Notice display may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: Using cabinets or stands recommended by the •... - Page 5 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic dealer. Do not cut off the mains plug. Do not use any other type of mains lead except the one supplied with this display.
-
Page 6: Safety Precautions
Safety Precautions We are not responsible for any product damage, etc. caused by failures in the installation environment for the pedestal or wall hanging bracket even during the warranty period. WARNING Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. ■... - Page 7 Unplug the power supply plug from the wall outlet, • local Panasonic dealer. and then contact the dealer for repairs. Do not touch the power supply cord or the plug To cut off the power supply to this Display completely, •...
- Page 8 Remove the batteries from the remote control CAUTION transmitter when not using for a long period of time. Do not place any objects on top of the Display. The battery may leak, heat, ignite or burst, resulting in • fire or damage to surrounding properties. Ventilation should not be impeded by covering the ventilation openings with items such as Remove exhausted batteries from the remote control...
-
Page 9: Precautions For Use
Precautions for use About the screws used when using a wall hanging bracket that conforms to VESA standards Depth of screw hole Cautions when installing Screw for fixing the Display onto the wall- Do not set up the Display outdoors. hanging bracket (not supplied with the Display) The Display is designed for indoor use. - Page 10 Change your password periodically. • the cables connected to the input terminals you Panasonic Connect Co., Ltd. or its affiliate companies • are currently not watching, or if you turn the power will never ask for your password directly. Do not...
- Page 11 Cleaning and maintenance First, remove the mains plug from the mains socket. Gently wipe the surface of the liquid crystal panel or cabinet by using a soft cloth to remove dirt. To remove stubborn dirt or fingerprints on the surface •...
-
Page 12: Accessories
(The actual part number may differ from the ones shown above.) Power supply cord ● In case you lost accessories, please purchase them TH-86EQ2W from your dealer. (Available from the customer (Approx. 2 m) service) ● 1JP155AF1U ●... - Page 13 Remote Control Batteries Attaching the Function Board When using a narrow-width function board, attach the Open the battery cover. supplied SLOT adaptor, and insert it to the expansion slot. Note ● Be sure to turn off the display unit and connected devices, remove the power plug from the socket, and disconnect the cables from the display.
- Page 14 Using the screw removed in step 1, Remove the 2 screws, and then fix the function board to the SLOT remove the expansion slot cover or adaptor. function board from the display unit. To remove the function board, hold the handle of the function board and pull it out slowly in the arrow direction.
- Page 15 Note ● When inserting the function board, be careful not to allow it to come into contact with the edge of the opening of the expansion slot. The display unit and the function board may be damaged. English...
-
Page 16: Cautions When Moving
Cautions when Kensington security moving 86-inch model 75-inch model The security slot of this unit is compatible with the 65-inch model Kensington security slot. 86-inch model 75-inch model 65-inch model The display has handles for carrying. Hold them when moving. Handle Note ●... -
Page 17: Eyebolt
Eyebolt φ 41 mm 75-inch model 86-inch model or less The display has holes for attaching eyebolts (M10). When installing, use them to suspend the display. Use the eyebolt only for temporary suspension or 12 mm to movement for installation. This cannot be used for 40 mm permanent hanging installation. -
Page 18: Connections
Connections 55-inch model 75-inch model 65-inch model 50-inch model 43-inch model Back of the unit AC cord connection and fixing / Cable fixing 86-inch model Back of the unit Insert the AC cord securely all the way seated on the back side of the unit. AC cord fixing AC cord (supplied) AC cord... - Page 19 Cable fixing Note ● 2 clampers are supplied with this unit. Fix the cables at location as shown below. If you need more clampers, purchase them from your dealer. (Available from the customer service) 86-inch model 75-inch model 65-inch model 43-inch model 55-inch model 50-inch model...
- Page 20 Video equipment connection SERIAL IN: SERIAL Input Terminal USB-C HOST: USB-C terminal Control the Display by connecting Connect a PC or video equipment to PC. that has a USB-C terminal. Also, this can be used to supply power LAN: LAN Terminal of up to 60 W to an external Control the Display by connecting device when the picture is...
- Page 21 Before connecting ● Before connecting cables, carefully read the operating instructions for the external device to be connected. ● Turn off the power of all devices before connecting cables. ● Take note of the following points before connecting the cables. Failure to do so may result in malfunctions.
-
Page 22: Identifying Controls
Identifying Controls Display INPUT MENU ENTER 1 Power Indicator / Remote control sensor The Power Indicator will light. When the power of the unit is ON (Main Power On / Off button : ON) 86-inch model 75-inch model 65-inch model ●... - Page 23 5 <MENU (Unit)> Displays the menu screen. 6 <+ (Unit)> / <- (Unit)> Adjusts the volume. On the menu screen, switches settings or adjusts settings level. 7 < (Unit)> / < (Unit)> Selects the setting item on menu screen. 8 <ENTER (Unit)> Configures the item on menu screen.
- Page 24 16 FUNCTION Remote Control Transmitter ● Displays [Function button guide]. 17 OFF TIMER ● Switches to stand-by after a fixed period. 18 Numeric buttons (1 - 6) ● Used as shortcut buttons by assigning frequently used operations. 19 Signal emission Note ●...
-
Page 25: Basic Controls
Basic Controls Connect the plug to the socket outlet. Note ● Main plug types vary between countries. The power plug shown at left may, therefore, not be the type fitted to your set. Main Power On / Off button ( ) (Back of the unit) ●... - Page 26 Please set the user name and password.If not set, settings] - [Colour design] is set to [Universal]. could not use the Web Control function and for communication control via a LAN (including Panasonic application software). These message displays can be set with the following Password policy...
-
Page 27: Specifications
86-inch model 1 895.0 mm (W) × 1 065.9 mm (H) × 2 174.2 mm (diagonal) / 74.60” (W) × 41.96” (H) × 85.60” Model No. (diagonal) : TH-86EQ2W 75-inch model 86-inch model : TH-75EQ2W 75-inch model 1 649.6 mm (W) × 927.9 mm (H) × 1 892.7 mm (diagonal) / 64.94”... - Page 28 Mass AUDIO IN Stereo mini jack (M3) (φ 3.5 mm) × 1, 0.5 Vrms 86-inch model Approx. 50.7 / 111.8 lbs net AUDIO OUT 75-inch model Stereo mini jack (M3) (φ 3.5 mm) × 1, 0.5 Vrms Approx. 37.3 / 82.2 lbs net Output: Variable (-∞ ‒ 0 dB) 65-inch model (1 kHz 0 dB input, 10 kΩ load) Approx. 29.7 / 65.5 lbs net 55-inch model SERIAL IN Approx.
- Page 29 Remote Control Transmitter Power source DC 3 V (battery (AAA/R03/LR03 type) × 2) Operating range Approx. 7 m (22.9 ft) (when operated directly in front of remote control sensor) Mass Approx. 63 / 2.22 oz (including batteries) Dimensions (W × H × D) 48 mm ×...
-
Page 30: Software License
At least three (3) years from delivery of this product, Panasonic Connect Co., Ltd. will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL V2.0, LGPL V2.1 or the other licenses with the obligation to do so, as well as the respective copyright... -
Page 31: Panasonic Professional Display
Whenever the date of original purchase cannot be satisfactorily determined, the date of manufacture of the unit will be deemed to be the effective date of the warranty. Panasonic reserves the right to audit and reject any warranty claim that cannot be substantiated. -
Page 32: Limited Warranty Statement
LIMITED WARRANTY STATEMENT English... - Page 33 Disposal of Old Equipment and Batteries Only for European Union and countries with recycling systems These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries must not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points in accordance with your national legislation.
- Page 34 Warranty Service purposes. Model Number Serial Number Panasonic Connect North America Unit of Panasonic Corporation of North America Executive Office : Two Riverfront Plaza, Newark, New Jersey 07102 Panasonic Canada Inc.
