Saramonic Vmic Stereo Manual

1 Product Introduction
1.1 General Introductions
The Saramonic Vmic Stereo is a stereo cardioid condenser
microphone that provides professional audio for DSLR cameras and
camcorders. The left and right microphone capsules record
high-quality stereo sound into your cameras and camcorders.
The Vmic Stereo allows you to adjust level control (-10dB, 0dB,
+20dB), high-pass filter (150 Hz) and high-frequency boost (+6dB) to
increase intelligibility of dialogue. The detachable 3.5mm cable
connects the Vmic Stereo to your camera's audio input, while the
stereo headphone output allows you to monitor the incoming audio.
The Saramonic specially designed shock mount system provides
isolation from vibration and mechanical noise.
1.2 Highlights
• Stereo cardioid condenser video microphone
• Integrated shock mount system
• High pass filter (150 Hz)
• High frequency boost (+6dB)
• Three position level control (-10dB, 0dB, +20dB)
• Headphone monitor output
• 1/8'' audio output to camera
• LED power on/low battery indicator
• Pop shield included
• Lightweight all-metal construction
• Powered by two AA batteries
1.3 Product Structure
1
2
3
4
5
1 LED indicator
2 Three position level control (-10dB, 0dB, +20dB)
3 Power button
High-pass filter (150Hz)
4
High frequency boost (+6dB)
5
Vmic Stereo
Stereo Cardioid Condenser Microphone for DSLR Cameras and
Camcorders
Audio output jack
6
Headphone output jack
7
Battery compartment
8 9
Integrated shock mount
9
Cold shoe mount
10
2 Set Up Guide
2.1 Install the battery
Unlock the battery compartment
1
Insert the AA batteries into place aligning + and - polarity as shown
2
Lock the battery compartment
3
2
